82100-6006

Obsolete

3M (TC)

CONN RCPT 100POS IDC 30AWG GOLD

Search across all available documentation for this part.

Obsolete

3M (TC)

CONN RCPT 100POS IDC 30AWG GOLD

Technical Specifications

Parameters and characteristics for this part

Part	Contact Finish	Wire Gauge	Contact Finish Thickness	Contact Finish Thickness	Cable Termination	Color	Number of Positions	Pitch [x]	Pitch [x]	Connector Type	Contact Type	Features	Row Spacing [x]	Row Spacing	Wire Type	Mounting Type	Number of Rows
3M (TC) 82100-6000	Gold	30 AWG	0.76 Ám	30 Áin	IDC	Gray	100	0.05 in	1.27 mm	Receptacle	Female Socket	Feed Through	0.1 in	2.54 mm	Ribbon Cable	Free Hanging (In-Line)	2
3M (TC) 82100-6006	Gold	30 AWG	0.76 Ám	30 Áin	IDC	Gray	100	0.05 in	1.27 mm	Receptacle	Female Socket	Feed Through Strain Relief	0.1 in	2.54 mm	Ribbon Cable	Free Hanging (In-Line)	2
3M (TC) 82100-6000RB	Gold	30 AWG	0.76 Ám	30 Áin	IDC	Gray	100	0.05 in	1.27 mm	Receptacle	Female Socket	Feed Through	0.1 in	2.54 mm	Ribbon Cable	Free Hanging (In-Line)	2

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

100 Position Rectangular Receptacle Connector IDC Gold 30 AWG

Technical documentation and resources
