MIC280-5BM6

Active

Micrel Inc.

IC SUPERVISOR SOT23-6

Search across all available documentation for this part.

Active

Micrel Inc.

IC SUPERVISOR SOT23-6

Technical Specifications

Parameters and characteristics commom to parts in this series

Specification	MIC280-5BM6	MIC280 Series

Mounting Type	Surface Mount	Surface Mount
Number of Voltages Monitored	-	1
Operating Temperature [Max]	125 °C	125 °C
Operating Temperature [Min]	-55 °C	-55 °C
Output	Open Drain or Open Collector	Open Drain or Open Collector
Package / Case	SOT-23-6	SOT-23-6
Reset	Active Low	Active Low
Reset Timeout	-	200 µs
Supplier Device Package	SOT-23-6	SOT-23-6
Type	Thermal	Thermal
Voltage - Threshold	2.95 V	2.65 - 2.95 V

IC SUPERVISOR SOT23-6

Part	Operating Temperature [Max]	Operating Temperature [Min]	Package / Case	Reset	Supplier Device Package	Mounting Type	Voltage - Threshold	Type	Output	Number of Voltages Monitored	Reset Timeout
Micrel Inc. MIC280-1BM6	125 °C	-55 °C	SOT-23-6	Active Low	SOT-23-6	Surface Mount	2.95 V	Thermal	Open Drain or Open Collector
Micrel Inc. MIC280-4BM6	125 °C	-55 °C	SOT-23-6	Active Low	SOT-23-6	Surface Mount	2.95 V	Thermal	Open Drain or Open Collector
Micrel Inc. MIC280-5BM6	125 °C	-55 °C	SOT-23-6	Active Low	SOT-23-6	Surface Mount	2.95 V	Thermal	Open Drain or Open Collector
Micrel Inc. MIC280-2BM6	125 °C	-55 °C	SOT-23-6	Active Low	SOT-23-6	Surface Mount	2.95 V	Thermal	Open Drain or Open Collector
Micrel Inc. MIC280-0YM6	125 °C	-55 °C	SOT-23-6	Active Low	SOT-23-6	Surface Mount	2.65 V	Thermal	Open Drain or Open Collector	1	200 µs
Micrel Inc. MIC280-7BM6	125 °C	-55 °C	SOT-23-6	Active Low	SOT-23-6	Surface Mount	2.95 V	Thermal	Open Drain or Open Collector
Micrel Inc. MIC280-3BM6	125 °C	-55 °C	SOT-23-6	Active Low	SOT-23-6	Surface Mount	2.95 V	Thermal	Open Drain or Open Collector

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	392	$ 0.77

General part information

Supervisor Open Drain or Open Collector Channel SOT-23-6
