AXE816124A

Active

Panasonic Electric Works

CONN HDR 16POS SMD GOLD

Search across all available documentation for this part.

Active

Panasonic Electric Works

CONN HDR 16POS SMD GOLD

Technical Specifications

Parameters and characteristics for this part

Specification	AXE816124A

Connector Type	Header, Center Strip Contacts
Contact Finish	Gold
Features	Solder Retention
Height Above Board	0.026 in
Height Above Board	0.65 mm
Mated Stacking Heights	0.8 mm
Mounting Type	Surface Mount
Number of Positions	16
Number of Rows	2
Pitch [x]	0.35 mm
Pitch [x]	0.014 in

Part	Connector Type	Mated Stacking Heights	Features	Mounting Type	Height Above Board	Height Above Board	Number of Rows	Pitch [x]	Pitch [x]	Contact Finish	Number of Positions
Panasonic Electric Works AXE816124A	Header Center Strip Contacts	0.8 mm	Solder Retention	Surface Mount	0.026 in	0.65 mm	2	0.35 mm	0.014 in	Gold	16

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Strip	500	$ 0.58

General part information

16 Position Connector Header, Center Strip Contacts Surface Mount Gold
