861-L03-213R001

Active

MH Connectors

CONN PLUG FMALE 3POS GOLD SOLDER

Search across all available documentation for this part.

Active

MH Connectors

CONN PLUG FMALE 3POS GOLD SOLDER

Technical Specifications

Parameters and characteristics for this part

Specification	861-L03-213R001

Color	Black, Silver
Connector Type	Female Sockets, Plug
Contact Finish - Mating	Gold
Contact Finish Thickness - Mating	Flash
Contact Material	Brass
Current Rating (Amps)	4 A
Features	Board Guide
Ingress Protection	IP67 - Dust Tight, Waterproof
Insert Material	Polybutylene Terephthalate (PBT)
Material Flammability Rating	UL94 V-0
Mounting Type	Through Hole, Right Angle, Panel Mount
Operating Temperature [Max]	85 °C
Operating Temperature [Min]	-40 °C
Orientation	A
Primary Material	Metal
Shell Finish	Nickel
Shell Material	Brass
Shell Size - Insert	M12-3
Shielding	Shielded
Termination	Solder
Voltage Rating	250 VDC

Part	Ingress Protection	Shell Size - Insert	Contact Finish Thickness - Mating	Shell Finish	Insert Material	Shell Material	Orientation	Operating Temperature [Max]	Operating Temperature [Min]	Material Flammability Rating	Voltage Rating	Contact Material	Mounting Type	Termination	Color	Shielding	Current Rating (Amps)	Features	Primary Material	Connector Type	Contact Finish - Mating
MH Connectors 861-L03-213R001	IP67 - Dust Tight Waterproof	M12-3	Flash	Nickel	Polybutylene Terephthalate (PBT)	Brass	A	85 °C	-40 °C	UL94 V-0	250 VDC	Brass	Panel Mount Right Angle Through Hole	Solder	Black Silver	Shielded	4 A	Board Guide	Metal	Female Sockets Plug	Gold

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Tray	25	$ 16.91

General part information

3 Position Circular Connector Plug, Female Sockets Solder
