Specification	D38999/26WE26HC

Applications	Aerospace, Aviation, Military
Color	Olive Drab
Connector Type	Male Pins, Plug
Contact Finish - Mating	Gold
Contact Material	Copper Alloy
Fastening Type	Threaded
Features	Self Locking
Grade	Military
Ingress Protection	Weathertight
Insert Material	Thermoplastic
Material Flammability Rating	UL94 V-0
Mounting Type	Free Hanging (In-Line)
Number of Positions	26
Operating Temperature (Max)	150 °C
Operating Temperature (Min)	-65 °C
Orientation	C
Qualification	MIL-DTL-38999 Series II
Shell Size - Insert (Maximum)	26
Shell Size - Insert (Minimum)	17
Shell Size (MIL)	E
Shielding	Shielded
Termination	Crimp
Voltage Rating	500 V

D38999/26WE Series

...

Part	Mounting Type	Connector Type	Fastening Type	Applications	Primary Material	Shell Finish	Ingress Protection Description	Ingress Protection IP Rating	Contact Finish Thickness - Mating	Features	Color	Shell Size - Insert (Minimum)	Shell Size - Insert (Maximum)	Number of Positions	Current Rating	Shell Size (MIL)	Shell Material	Operating Temperature (Min)	Operating Temperature (Max)	Contact Material	Orientation	Grade	Contact Finish - Mating	Insert Material	Shielding	Termination	Qualification	Shell Size - Insert Length	Shell Size - Insert Width	Ingress Protection	Note	Contact Type	Contact Size Options	Housing Color	Type	Contact Shape	Contact Size
Amphenol Aerospace Operations D38999/26WE26SB	Free Hanging (In-Line)	Female Sockets Plug	Threaded	Aviation Marine Military	Metal	Olive Drab Cadmium	Dust Tight Waterproof	IP67	50 µin	Coupling Nut	Olive Drab	17	26	26	7.5 A	E	Aluminum	-65 °C	175 °C	Copper Alloy	B	Military	Gold	Thermoplastic	Shielded	Crimp	MIL-DTL-38999 Series III
Amphenol Aerospace Operations D38999/26WE6PN	Free Hanging (In-Line)	Male Pins Plug	Threaded	Aerospace Aviation Marine Military	Metal	Olive Drab Cadmium			50 µin	Coupling Nut	Olive Drab			6		E	Aluminum	-65 °C	175 °C	Copper Alloy	N (Normal)	Military	Gold		Shielded	Crimp	MIL-DTL-38999 Series III	17 mm	6 mm	Environment Resistant
Amphenol Aerospace Operations D38999/26WE26SAL
Amphenol Aerospace Operations D38999/26WE26JB	Free Hanging (In-Line)	Female Sockets Plug Receptacle	Threaded	Aviation Marine Military	Metal	Olive Drab Cadmium			100 µin	Coupling Nut Self Locking	Olive Drab	17	26	26		E	Aluminum	-65 °C	175 °C	Copper Alloy	B	Military	Gold		Shielded	Crimp	MIL-DTL-38999 Series III			Environment Resistant
Amphenol Aerospace Operations D38999/26WE6HN	Free Hanging (In-Line)	Male Pins Plug	Threaded	Aerospace Aviation Military	Metal	Olive Drab Cadmium			100 µin	Coupling Nut	Olive Drab			6		E	Aluminum	-65 °C	175 °C	Copper Alloy	N (Normal)	Military	Gold		Shielded	Crimp	MIL-DTL-38999 Series III	17 mm	6 mm	Environment Resistant
Amphenol Aerospace Operations D38999/26WE35AA	Free Hanging (In-Line)	Plug Housing	Threaded		Metal	Cadmium						17	35	55		E	Aluminum	-65 °C	175 °C		A	Military		Thermoplastic	Shielded		MIL-DTL-38999 Series III			Environment Resistant	Contacts Not Included	Crimp	22D	Olive Drab	For Male Pins	Circular
Amphenol Aerospace Operations D38999/26WE26AA	Free Hanging (In-Line)	Plug Housing	Threaded			Cadmium				Coupling Nut Self Locking		17	26	26		E	Aluminum	-65 °C	175 °C		A	Military			Shielded		MIL-DTL-38999 Series III			Environment Resistant	Contacts Not Included	Crimp		Olive Drab	For Male Pins	Circular	20
Amphenol Aerospace Operations D38999/26WE35SN-LC	Free Hanging (In-Line)	Plug Housing	Threaded			Cadmium	Dust Tight Waterproof	IP67		Coupling Nut		17	35	55		E	Aluminum	-65 °C	175 °C		N (Normal)	Military		Thermoplastic	Shielded		MIL-DTL-38999 Series III				Contacts Not Included	Crimp	22D	Olive Drab	For Female Sockets	Circular
Amphenol Aerospace Operations D38999/26WE35PAL	Free Hanging (In-Line)	Plug Housing	Threaded		Metal	Cadmium				Coupling Nut		17	35	6 55		E	Aluminum	-65 °C	175 °C		A	Military		Thermoplastic	Shielded		MIL-DTL-38999 Series III			Environment Resistant	Contacts Not Included	Crimp	22D	Olive Drab	For Male Pins	Circular
Amphenol Aerospace Operations D38999/26WE35BE	Free Hanging (In-Line)	Plug Housing	Threaded		Metal	Cadmium				Coupling Nut Self Locking		17	35	55		E	Aluminum	-65 °C	175 °C		E	Military		Thermoplastic	Shielded		MIL-DTL-38999 Series III			Environment Resistant	Contacts Not Included	Crimp	22D	Olive Drab	For Female Sockets	Circular
