CI5202P1V00-LF

Obsolete

Cvilux USA

2 POS 3.96MM(.156) WIRE TO BOARD

Search across all available documentation for this part.

Obsolete

Cvilux USA

2 POS 3.96MM(.156) WIRE TO BOARD

Technical Specifications

Parameters and characteristics for this part

Specification	CI5202P1V00-LF

Connector Type	Header
Contact Finish - Post	Tin
Contact Finish Thickness - Mating	120 µin
Contact Finish Thickness - Mating	3.05 Ám
Contact Finish Thickness - Post	120 Áin
Contact Finish Thickness - Post	3.05 Ám
Contact Length - Mating	7.7 mm
Contact Length - Mating	0.303 in
Contact Length - Post	0.146 in
Contact Length - Post	3.7 mm
Contact Material	Brass
Contact Shape	Square
Contact Type	Male Pin
Current Rating (Amps)	7 A
Fastening Type	Locking Ramp
Insulation Color	Natural
Insulation Height	0.37 in
Insulation Height	9.4 mm
Insulation Material	Polyamide (PA46), Nylon 4/6
Material Flammability Rating	UL94 V-0
Mounting Type	Through Hole
Number of Positions	2
Number of Positions Loaded	All
Number of Rows	1
Operating Temperature [Max]	105 ░C
Operating Temperature [Min]	-25 °C
Overall Contact Length	0.575 in
Overall Contact Length	14.6 mm
Pitch - Mating	0.156 in
Pitch - Mating	3.96 mm
Shrouding	Shrouded - 1 Wall
Style	Board to Cable/Wire
Termination	Solder
Voltage Rating	250 VAC

Part	Contact Length - Mating	Contact Length - Mating	Overall Contact Length	Overall Contact Length	Current Rating (Amps)	Connector Type	Mounting Type	Contact Type	Style	Contact Material	Insulation Color	Number of Positions	Operating Temperature [Min]	Operating Temperature [Max]	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Material Flammability Rating	Contact Finish - Post	Fastening Type	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Number of Rows	Shrouding	Insulation Height	Insulation Height	Pitch - Mating	Pitch - Mating	Contact Shape	Voltage Rating	Contact Length - Post	Contact Length - Post	Termination	Number of Positions Loaded	Insulation Material
Cvilux USA CI5202P1V00-LF	7.7 mm	0.303 in	0.575 in	14.6 mm	7 A	Header	Through Hole	Male Pin	Board to Cable/Wire	Brass	Natural	2	-25 °C	105 ░C	120 µin	3.05 Ám	UL94 V-0	Tin	Locking Ramp	120 Áin	3.05 Ám	1	Shrouded - 1 Wall	0.37 in	9.4 mm	0.156 in	3.96 mm	Square	250 VAC	0.146 in	3.7 mm	Solder	All	Polyamide (PA46) Nylon 4/6
