EVAL MAX98374 CLASS D AMP
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
MAX98374FEVSYS#
ActiveAnalog Devices Inc./Maxim Integrated
EVAL MAX98374 CLASS D AMP
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | MAX98374FEVSYS# | MAX98374 Series |
|---|---|---|
| Board Type | Fully Populated | Fully Populated |
| Max Output Power x Channels @ Load | 16 W | 12.5 - 16 W |
| Max Output Power x Channels @ Load [custom] | 1 | 1 |
| Mounting Type | - | Surface Mount |
| Operating Temperature | - | 85 °C |
| Operating Temperature | - | -40 °C |
| Output Type | 1-Channel (Mono) | 1-Channel (Mono) |
| Package / Case | - | 22-PowerUFQFN, WLBGA, 25-WFBGA |
| Supplied Contents | Cable(s), Board(s) | Cable(s), Board(s) |
| Supplier Device Package | - | 25-WLP (2.17x2.25) |
| Type | - | Class D |
| Utilized IC / Part | MAX98374 | MAX98374 |
| Voltage - Supply [Max] | 16 V | 16 V |
| Voltage - Supply [Min] | 5.5 V | 5.5 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 303.78 | |
MAX98374 Series
EVAL MAX98374 CLASS D AMP
| Part | Supplied Contents | Voltage - Supply [Max] | Voltage - Supply [Min] | Max Output Power x Channels @ Load [custom] | Max Output Power x Channels @ Load | Utilized IC / Part | Board Type | Output Type | Mounting Type | Package / Case | Type | Operating Temperature [Max] | Operating Temperature [Min] | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Analog Devices Inc./Maxim Integrated MAX98374FEVSYS# | Board(s), Cable(s) | 16 V | 5.5 V | 1 | 16 W | MAX98374 | Fully Populated | 1-Channel (Mono) | ||||||
Analog Devices Inc./Maxim Integrated MAX98374EFF+T | 16 V | 5.5 V | 1 | 12.5 W | 1-Channel (Mono) | Surface Mount | 22-PowerUFQFN | Class D | 85 °C | -40 °C | ||||
Analog Devices Inc./Maxim Integrated MAX98374EWA+T | 16 V | 5.5 V | 1 | 12.5 W | 1-Channel (Mono) | Surface Mount | 25-WFBGA, WLBGA | Class D | 85 °C | -40 °C | 25-WLP (2.17x2.25) | |||
Analog Devices Inc./Maxim Integrated MAX98374EFF+ | 16 V | 5.5 V | 1 | 12.5 W | 1-Channel (Mono) | Surface Mount | 22-PowerUFQFN | Class D | 85 °C | -40 °C | ||||
Analog Devices Inc./Maxim Integrated MAX98374EVSYS# | Board(s) | 16 V | 5.5 V | 1 | 16 W | MAX98374 | Fully Populated | 1-Channel (Mono) |
Description
General part information
MAX98374 Series
MAX98374 - 1-Channel (Mono) Output Class D Audio Amplifier Evaluation Board
