Specification	2170768-2

Connector Pin Configuration (Columns)	3 pins
Connector Pin Configuration (Rows)	1 pins
Connector Style	Cage, Ganged with Heat Sink
Connector Type	QSFP28
Features	EMI Shielded
Mounting Type	Through Hole, Right Angle
Termination	Press-Fit

2170768 Series

Part	Features	Connector Pin Configuration (Columns)	Connector Style	Connector Pin Configuration (Rows)	Mounting Type	Connector Type	Termination
TE Connectivity AMP Connectors 2170768-5	EMI Shielded	3 pins	Cage Ganged with Heat Sink	1 pins	Right Angle Through Hole	QSFP28	Press-Fit
TE Connectivity AMP Connectors 2170768-1	EMI Shielded	3 pins	Cage Ganged with Heat Sink	1 pins	Right Angle Through Hole	QSFP28	Press-Fit
TE Connectivity AMP Connectors 2170768-2	EMI Shielded	3 pins	Cage Ganged with Heat Sink	1 pins	Right Angle Through Hole	QSFP28	Press-Fit

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Create a free account to access distributor pricing data.

3D models and CAD resources for this part

Technical documentation and resources
