IP5 Series

RF Connectors / Coaxial Connectors 4.00 mm IsoRate 50 Ohm High-Isolation RF Plug Strip

Part	Mounting Type	Connector Style	Impedance	Connector Type	Frequency - Max	Center Contact Material	Contact Termination	Number of Ports	Housing Color	Dielectric Material	Center Contact Plating	Operating Temperature (Max)	Operating Temperature (Min)	Body Material	Voltage Rating	Fastening Type
Samtec Inc. IP5-08-05.0-L-D-1-TR	Through Hole	Coaxial	50 Ohm	Female Socket Plug	9.5 GHz	Copper Alloy	Solder	16	Black
Samtec Inc. IP5-06-05.0-L-S-1-TR	Through Hole	Coaxial	50 Ohm	Female Socket Plug	9.5 GHz	Copper Alloy	Solder	6	Black	Liquid Crystal Polymer (LCP)	Gold	125 °C	-55 °C	Nylon PA Polyamide	200 VDC
Samtec Inc. IP5-08-05.0-L-S-1-L-TR	Through Hole	Coaxial	50 Ohm	Female Socket Plug	9.5 GHz	Copper Alloy	Solder	8	Black							Latch Lock

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Create a free account to access distributor pricing data.

3D models and CAD resources for this part

Technical documentation and resources
