9576B

Active

3M (TC)

TAPE SPLICING BLACK 2"X60YDS

Search across all available documentation for this part.

Active

3M (TC)

TAPE SPLICING BLACK 2"X60YDS

Technical Specifications

Parameters and characteristics for this part

Specification	9576B

Adhesive	Acrylic, 400
Backing, Carrier	Polypropylene Film
Color	Black
Length	60 yds
Length	55 m
Length	180 ft
Shelf Life	24 Months
Shelf Life Start	Date of Manufacture
Storage/Refrigeration Temperature	70 °F
Storage/Refrigeration Temperature	21 °C
Tape Type	Splicing
Temperature Range	125 °F
Temperature Range	52 °C
Thickness	0.102 mm
Thickness	4 mils
Thickness	0.004 in
Thickness - Adhesive	0.003 "
Thickness - Adhesive	0.076 mm
Thickness - Adhesive	3 mils
Thickness - Backing, Carrier	1 mils
Thickness - Backing, Carrier	0.025 mm
Thickness - Backing, Carrier	0.001 "
Usage	General Purpose, Splicing, Adhesion
Width [y]	2 "
Width [y]	50.8 mm

Part	Thickness	Thickness	Thickness	Adhesive	Storage/Refrigeration Temperature	Storage/Refrigeration Temperature	Thickness - Adhesive	Thickness - Adhesive	Thickness - Adhesive	Backing, Carrier	Temperature Range	Temperature Range	Usage	Shelf Life	Width [y]	Width [y]	Tape Type	Length	Length	Length	Thickness - Backing, Carrier	Thickness - Backing, Carrier	Thickness - Backing, Carrier	Color	Shelf Life Start
3M (TC) 9576B	0.102 mm	4 mils	0.004 in	Acrylic 400	70 °F	21 °C	0.003 "	0.076 mm	3 mils	Polypropylene Film	125 °F	52 °C	Adhesion General Purpose Splicing	24 Months	2 "	50.8 mm	Splicing	60 yds	55 m	180 ft	1 mils	0.025 mm	0.001 "	Black	Date of Manufacture

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Splicing Tape Acrylic, 400 Adhesive Black 2.00" (50.80mm) X 180' (55.0m) 60 yds
