71M6511-DB
ActiveAnalog Devices Inc./Maxim Integrated
BOARD DEMO 71M6511 ENERGY METER
Deep-Dive with AI
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | 71M6511-DB | 71M6511 Series |
|---|---|---|
| Embedded | False | False |
| Function | Energy/Power Meter | Energy/Power Meter |
| Input Impedance | - | 90 kOhm |
| Input Impedance | - | 40 kOhm |
| Measurement Error | - | 0.1 % |
| Meter Type | - | Single Phase |
| Mounting Type | - | Surface Mount |
| Operating Temperature | - | 85 °C |
| Operating Temperature | - | -40 °C |
| Package / Case | - | 64-LQFP |
| Supplied Contents | Cable(s), Power Supply, Board(s) | Cable(s), Power Supply, Board(s) |
| Supplier Device Package | - | 64-LQFP (10x10) |
| Type | Power Management | Power Management |
| Voltage - I/O High | - | 2 V |
| Voltage - I/O Low | - | 0.8 V |
| Voltage - Supply | - | 3 V |
| Voltage - Supply | - | 3.6 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
71M6511 Series
IC ENERGY METER RESIDENT 64-LQFP
| Part | Input Impedance [Max] | Input Impedance [Min] | Mounting Type | Operating Temperature [Max] | Operating Temperature [Min] | Voltage - I/O High | Voltage - Supply [Min] | Voltage - Supply [Max] | Supplier Device Package | Package / Case | Measurement Error | Voltage - I/O Low | Meter Type | Supplied Contents | Type | Function | Embedded |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Analog Devices Inc./Maxim Integrated 71M6511-IGTR/F | 90 kOhm | 40 kOhm | Surface Mount | 85 °C | -40 °C | 2 V | 3 V | 3.6 V | 64-LQFP (10x10) | 64-LQFP | 0.1 % | 0.8 V | Single Phase | ||||
Analog Devices Inc./Maxim Integrated 71M6511-DB | Board(s), Cable(s), Power Supply | Power Management | Energy/Power Meter | ||||||||||||||
Analog Devices Inc./Maxim Integrated 71M6511-IGT/F | 90 kOhm | 40 kOhm | Surface Mount | 85 °C | -40 °C | 2 V | 3 V | 3.6 V | 64-LQFP (10x10) | 64-LQFP | 0.1 % | 0.8 V | Single Phase | ||||
Analog Devices Inc./Maxim Integrated 71M6511H-IGT/F | 90 kOhm | 40 kOhm | Surface Mount | 85 °C | -40 °C | 2 V | 3 V | 3.6 V | 64-LQFP (10x10) | 64-LQFP | 0.1 % | 0.8 V | Single Phase | ||||
Analog Devices Inc./Maxim Integrated 71M6511H-IGTR/F | 90 kOhm | 40 kOhm | Surface Mount | 85 °C | -40 °C | 2 V | 3 V | 3.6 V | 64-LQFP (10x10) | 64-LQFP | 0.1 % | 0.8 V | Single Phase |
Description
General part information
71M6511 Series
71M6511 Energy/Power Meter Power Management Evaluation Board
