5300UE 010U1000

Active

Belden Inc.

CABLE 2COND 18AWG BLACK

Search across all available documentation for this part.

Active

Belden Inc.

CABLE 2COND 18AWG BLACK

Technical Specifications

Parameters and characteristics for this part

Specification	5300UE 010U1000

Cable Type	Multi-Conductor
Conductor Insulation	Polypropylene (PP)
Conductor Material	Copper, Bare
Conductor Strand [custom]	26 AWG
Conductor Strand [custom]	7
Features	Rip Cord
Jacket (Insulation) Diameter [diameter]	4.01 mm
Jacket (Insulation) Diameter [diameter]	0.158 in
Jacket (Insulation) Material	Poly-Vinyl Chloride (PVC), Riser
Jacket (Insulation) Thickness	0.432 mm
Jacket (Insulation) Thickness	0.017 in
Jacket Color	Black
Length	1000 ft
Length	304.8 m
Number of Conductors	2
Ratings	UL Style CMR
Usage	Sound, Security
Voltage	300 V
Wire Gauge	18 AWG

Part	Usage	Jacket (Insulation) Thickness	Jacket (Insulation) Thickness	Number of Conductors	Jacket (Insulation) Material	Wire Gauge	Jacket Color	Cable Type	Conductor Strand [custom]	Conductor Strand [custom]	Conductor Insulation	Features	Conductor Material	Voltage	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Ratings	Length	Length	Length [x]	Length [x]
Belden Inc. 5300UE 0101000	Security Sound	0.432 mm	0.017 in	2	Poly-Vinyl Chloride (PVC) Riser	18 AWG	Black	Multi-Conductor	26 AWG	7	Polypropylene (PP)	Rip Cord	Copper Bare	300 V	4.01 mm	0.158 in	UL Style CMR	1000 ft	304.8 m
Belden Inc. 5300UE 008U500	Security Sound	0.432 mm	0.017 in	2	Poly-Vinyl Chloride (PVC) Riser	18 AWG	Gray	Multi-Conductor	26 AWG	7	Polypropylene (PP)	Rip Cord	Copper Bare	300 V	4.01 mm	0.158 in	UL Style CMR			500 '	152.4 m
Belden Inc. 5300UE 010U1000	Security Sound	0.432 mm	0.017 in	2	Poly-Vinyl Chloride (PVC) Riser	18 AWG	Black	Multi-Conductor	26 AWG	7	Polypropylene (PP)	Rip Cord	Copper Bare	300 V	4.01 mm	0.158 in	UL Style CMR	1000 ft	304.8 m
Belden Inc. 5300UE 009U1000	Security Sound	0.432 mm	0.017 in	2	Poly-Vinyl Chloride (PVC) Riser	18 AWG		Multi-Conductor	26 AWG	7	Polypropylene (PP)	Rip Cord	Copper Bare	300 V	4.01 mm	0.158 in	UL Style CMR	1000 ft	304.8 m
Belden Inc. 5300UE 001U1000	Security Sound	0.432 mm	0.017 in	2	Poly-Vinyl Chloride (PVC) Riser	18 AWG	Brown	Multi-Conductor	26 AWG	7	Polypropylene (PP)	Rip Cord Water-Blocked	Copper Bare	300 V	4.01 mm	0.158 in	UL Style CMR	1000 ft	304.8 m

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Spool	1000	$ 0.30

General part information

2 Conductor Multi-Conductor Cable Black 18 AWG 1000.0' (304.8m)
