3M5557NP-4.5MMSQ-100

Obsolete

3M (TC)

TAPE INDICATOR WHITE 0.18"X0.18"

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

3M5557NP-4.5MMSQ-100

Obsolete

3M (TC)

TAPE INDICATOR WHITE 0.18"X0.18"

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	3M5557NP-4.5MMSQ-100

Adhesive	Acrylic
Backing, Carrier	Polyester Film
Color	White
Length [x]	4.5 mm
Length [x]	0.18 in
Shelf Life	12 Months
Shelf Life Start	Date of Manufacture
Storage/Refrigeration Temperature [Max]	80 °F, 27 °C
Storage/Refrigeration Temperature [Min]	60 °F, 16 °C
Tape Type	Indicator
Thickness	0.218 mm
Thickness	8.6 mils
Thickness	0.0086 in
Usage	Water Indication
Width [y]	0.18 "
Width [y]	4.5 mm

5557NP Series

Part	Storage/Refrigeration Temperature [Min]	Storage/Refrigeration Temperature [Max]	Backing, Carrier	Color	Length	Length	Shelf Life Start	Adhesive	Usage	Shelf Life	Thickness	Thickness	Thickness	Tape Type	Width [y]	Width [y]	Length [x]	Length [x]	Width	Width	Width [diameter]	Width [diameter]	Width [x]	Width [x]
3M (TC) 3M5557NP-3MMSQ-100	16 °C 60 °F	27 °C 80 °F	Polyester Film	White	0.12 in	3 mm	Date of Manufacture	Acrylic	Water Indication	12 Months	0.218 mm	8.6 mils	0.0086 in	Indicator
3M (TC) 3M5557NP-4.5MMSQ-100	16 °C 60 °F	27 °C 80 °F	Polyester Film	White			Date of Manufacture	Acrylic	Water Indication	12 Months	0.218 mm	8.6 mils	0.0086 in	Indicator	0.18 "	4.5 mm	4.5 mm	0.18 in
3M (TC) 3M5557NP-5MMSQ-100	16 °C 60 °F	27 °C 80 °F	Polyester Film	White	0.2 in	5 mm	Date of Manufacture	Acrylic	Water Indication	12 Months	0.218 mm	8.6 mils	0.0086 in	Indicator	0.2 in	5 mm
3M (TC) 3M5557NP-4MM-DISC-100	16 °C 60 °F	27 °C 80 °F	Polyester Film	White			Date of Manufacture	Acrylic	Water Indication	12 Months	0.218 mm	8.6 mils	0.0086 in	Indicator					0.16 in	4 mm
3M (TC) 3M5557NP-2MM-DISC-100	16 °C 60 °F	27 °C 80 °F	Polyester Film	White			Date of Manufacture	Acrylic	Water Indication	12 Months	0.218 mm	8.6 mils	0.0086 in	Indicator							2.03 mm	0.08 in
3M (TC) 3M5557NP-4MMSQ-100	16 °C 60 °F	27 °C 80 °F	Polyester Film	White			Date of Manufacture	Acrylic	Water Indication	12 Months	0.218 mm	8.6 mils	0.0086 in	Indicator			4 mm	0.16 in					4 mm	0.16 "
3M (TC) 3M5557NP-3MM-DISC-100	16 °C 60 °F	27 °C 80 °F	Polyester Film	White			Date of Manufacture	Acrylic	Water Indication	12 Months	0.218 mm	8.6 mils	0.0086 in	Indicator					0.12 "	3 mm

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Description

General part information

5557NP Series

Indicator Tape Acrylic Adhesive White 0.18" (4.50mm) X 0.18" (4.50mm)
