Cable Assemblies

1200845187

Active

ULTRA-LOCK (M12) RECEPTACLE, 8 POLES, M16X1.5 MOUNTING THREADS, MALE (STRAIGHT) TO 24 AWG PVC LEADS, 0.30M (11.81") LENGTH

Cable Assemblies

1200845187

Active

Molex

ULTRA-LOCK (M12) RECEPTACLE, 8 POLES, M16X1.5 MOUNTING THREADS, MALE (STRAIGHT) TO 24 AWG PVC LEADS, 0.30M (11.81") LENGTH

Specifications Series Pricing CAD Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	1200845187

1st Connector Gender	Male Pins
1st Connector Mounting Type	Panel Mount
1st Connector Number of Positions	8 positions
1st Connector Number of Positions Loaded	All
1st Connector Shell Size - Insert	M16
1st Connector Type	Receptacle
2nd Connector Type	Wire Leads
Assembly Configuration	Standard
Cable Material	Polyvinyl Chloride (PVC)
Cable Type	Individual
Color	Multiple
Ingress Protection Description	Water Resistant, Dust Tight, Waterproof
Ingress Protection IP Rating	IP67, IP69K
Length	0.98 ft
Shielding	Shielded
Usage	Industrial Environments

120084 Series

Ultra-Lock (M12) Receptacle, 4 Poles, M16x1.5 Mounting Threads, Male (Straight) to 0.34mm2 PVC Leads, 0.30m (11.81") Length

Part	Shielding	Color	2nd Connector Type	1st Connector Number of Positions Loaded	1st Connector Mounting Type	Usage	1st Connector Number of Positions	Length	Cable Type	Assembly Configuration	Cable Material	1st Connector Gender	1st Connector Shell Size - Insert	1st Connector Type	Ingress Protection IP Rating	Ingress Protection Description	Shell Finish	Number of Positions	Fastening Type	Orientation	Voltage Rating (DC)	Voltage Rating (AC)	Connector Type	Shell Material	Shell Size - Insert	Contact Finish - Mating	Current Rating	Termination	Mounting Feature	Primary Material	Mounting Type	Operating Temperature (Min)	Operating Temperature (Max)	Voltage Rating	Voltage Rating (Type)	Material Flammability Rating	Contact Material	Insert Material	Applications	1st Connector Orientation
Molex 1200845187	Shielded	Multiple	Wire Leads	All	Panel Mount	Industrial Environments	8 positions	0.98 ft	Individual	Standard	Polyvinyl Chloride (PVC)	Male Pins	M16	Receptacle	IP67 IP69K	Dust Tight Water Resistant Waterproof
Molex 1200845013	Unshielded	Multiple	Wire Leads	All	Panel Mount	Industrial Environments	12 positions	0.98 ft	Individual	Standard	Polyvinyl Chloride (PVC)	Female Sockets	M12	Receptacle	IP69K	Dust Tight High Temp Water Jets Waterproof
Molex 1200840047	Shielded	Silver													IP69K	Dust Tight High Temp Water Jets Waterproof	Nickel	8	Threaded	Keyed	36 VDC	30 VAC	Male Pins Receptacle	Brass	M12-8	Gold	2 A	Solder	Bulkhead Front Side Nut	Metal	Panel Mount Through Hole	-25 °C	90 °C
Molex 1200840031		Silver													IP69K	Dust Tight High Temp Water Jets Waterproof	Nickel	5	Push-Pull	Keyed			Male Pins Receptacle	Copper Zinc	M12-5	Gold	4 A	Solder	Bulkhead Front Side Nut	Metal	Panel Mount Through Hole	-25 °C	90 °C	60 V	DC	UL94 V-0	Copper Alloy	Nylon 6/6 PA66 Polyamide	Industrial Telecommunications
Molex 1200845181	Shielded	Silver													IP69K	Dust Tight High Temp Water Jets Waterproof	Nickel	5	Threaded	Keyed			Male Pins Receptacle	Brass	M12-5	Gold	4 A	Solder	Bulkhead Front Side Nut	Metal	Panel Mount Through Hole	-25 °C	90 °C	60 V
Molex 1200845192	Shielded	Multiple	Wire Leads	All	Panel Mount		12 positions	0.98 ft	Individual	Standard	Polyvinyl Chloride (PVC)	Male Pins	M12	Receptacle
Molex 1200845096	Unshielded	Multiple	Wire Leads	All	Panel Mount	Industrial Environments	8 positions	0.98 ft	Individual	Standard	Polyvinyl Chloride (PVC)	Male Pins	M12	Receptacle	IP67 IP69K	Dust Tight Water Resistant Waterproof																								A
Molex 1200840025	Unshielded	Multiple	Wire Leads	All	Panel Mount	Industrial Environments	5 positions	0.98 ft	Individual	Standard	Polyvinyl Chloride (PVC)	Female Sockets	M12	Plug	IP67	Dust Tight Waterproof																								A
Molex 1200840009
Molex 1200840032	Unshielded	Silver													IP67 IP68 IP69K	Dust Tight Water Resistant Waterproof	Nickel	8	Threaded	Keyed	36 VDC	30 VAC	Male Pins Receptacle	Brass	M12-8	Gold	2 A	Solder	Bulkhead Front Side Nut	Metal	Panel Mount Through Hole	-25 °C	90 °C				Brass	Nylon PA Polyamide	Industrial
