CB-05PMFP-LC7001

Active

Amphenol LTW

CERES, MIDDLE SIZE, 10A, 05 PINS

Search across all available documentation for this part.

Active

Amphenol LTW

CERES, MIDDLE SIZE, 10A, 05 PINS

Technical Specifications

Parameters and characteristics for this part

Specification	CB-05PMFP-LC7001

Color	Black
Connector Type	Receptacle, Female Sockets
Contact Finish - Mating	Gold
Contact Material	Copper Alloy
Current Rating (Amps)	10 A
Fastening Type	Bayonet Lock
Ingress Protection	IP67 - Dust Tight, Waterproof
Insert Material	Polyamide (PA), Nylon, Glass Filled
Mounting Feature	Bulkhead - Front Side Nut
Mounting Type	Through Hole, Panel Mount
Operating Temperature [Max]	105 ░C
Operating Temperature [Min]	-40 °C
Orientation	Keyed
Primary Material	Plastic
Shell Material	Nylon, Glass Filled, Polyamide (PA)
Shell Size - Insert	C
Shielding	Unshielded
Termination	Solder
Voltage Rating	250 VDC

Part	Contact Finish - Mating	Shielding	Voltage Rating	Orientation	Connector Type	Termination	Mounting Type	Contact Material	Current Rating (Amps)	Color	Shell Size - Insert	Fastening Type	Insert Material	Shell Material	Operating Temperature [Min]	Operating Temperature [Max]	Mounting Feature	Ingress Protection	Primary Material
Amphenol LTW CB-05PMFP-LC7001	Gold	Unshielded	250 VDC	Keyed	Receptacle Female Sockets	Solder	Panel Mount Through Hole	Copper Alloy	10 A	Black	C	Bayonet Lock	Polyamide (PA) Nylon Glass Filled	Glass Filled Nylon Polyamide (PA)	-40 °C	105 ░C	Bulkhead - Front Side Nut	IP67 - Dust Tight Waterproof	Plastic
Amphenol LTW CB-05PMFP-SC7001	Gold	Unshielded	250 VDC	Keyed	Receptacle Female Sockets	Solder	Panel Mount Through Hole	Copper Alloy	10 A	Black	C		Polyamide (PA) Nylon Glass Filled	Glass Filled Nylon Polyamide (PA)	-40 °C	105 ░C	Bulkhead - Front Side Nut	IP67 - Dust Tight Waterproof	Plastic

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	10	$ 9.14

General part information

5 Position Circular Connector Receptacle, Female Sockets Solder
