WFI32E03UE-I
ActiveGLOBAL REGULATORY CERTIFIED, RF READY, WI-FI® MCU MODULE WITH U.FL CONNECTOR AND 2 MB FLASH
Deep-Dive with AI
Search across all available documentation for this part.
WFI32E03UE-I
ActiveGLOBAL REGULATORY CERTIFIED, RF READY, WI-FI® MCU MODULE WITH U.FL CONNECTOR AND 2 MB FLASH
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | WFI32E03UE-I |
|---|---|
| Antenna Type | Antenna Not Included, U.FL |
| Current - Receiving [Max] | 162 mA |
| Current - Receiving [Min] | 73 mA |
| Current - Transmitting [Max] | 359 mA |
| Current - Transmitting [Min] | 169 mA |
| Data Rate | 54 Mbps |
| Frequency | 2.4 GHz |
| Memory Size | 512 kB, 2 MB |
| Modulation | DSSS, OFDM, CCK |
| Mounting Type | Surface Mount |
| Operating Temperature [Max] | 85 °C |
| Operating Temperature [Min] | -40 °C |
| Package / Case | 54-SMD Module |
| Power - Output | 21.5 dBm |
| Protocol | 802.11b/g/n |
| RF Family/Standard | WiFi |
| Sensitivity | -100 dBm |
| Serial Interfaces | I2S, SPI, Ethernet, JTAG, UART, USB, I2C, GPIO |
| Utilized IC / Part | PIC32MZ2051W104132-I/NX |
| Voltage - Supply [Max] | 3.63 V |
| Voltage - Supply [Min] | 2.97 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tray | 1 | $ 9.56 | |
| Microchip Direct | TRAY | 1 | $ 10.35 | |
| 100 | $ 9.71 | |||
| 1000 | $ 8.90 | |||
| 5000 | $ 8.50 | |||
WFI32E03UE Series
Global Regulatory Certified, RF Ready, Wi-Fi® MCU Module With U.FL Connector and 2 MB Flash
| Part | Mounting Type | Power - Output | RF Family/Standard | Utilized IC / Part | Sensitivity | Protocol | Serial Interfaces | Current - Transmitting [Max] | Current - Transmitting [Min] | Memory Size | Frequency | Package / Case | Current - Receiving [Max] | Current - Receiving [Min] | Modulation | Operating Temperature [Max] | Operating Temperature [Min] | Antenna Type | Voltage - Supply [Min] | Voltage - Supply [Max] | Data Rate |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Microchip Technology WFI32E03UE-I | Surface Mount | 21.5 dBm | WiFi | PIC32MZ2051W104132-I/NX | -100 dBm | 802.11b/g/n | Ethernet, GPIO, I2C, I2S, JTAG, SPI, UART, USB | 359 mA | 169 mA | 2 MB, 512 kB | 2.4 GHz | 54-SMD Module | 162 mA | 73 mA | CCK, DSSS, OFDM | 85 °C | -40 °C | Antenna Not Included, U.FL | 2.97 V | 3.63 V | 54 Mbps |
Description
General part information
WFI32E03UE Series
WFI32E03UE is a high-performance, Wi-Fi MCU module that is well suited for industrial applications. This module is built on the PIC32MZ2051-W1 SoC, a robust Wi-Fi MCU with a 200-MHz MIPS processor and 2 MB of program memory. Along with a powerful core, our WFI32E03UE module provides advanced features that will help you to realize your application.
**Industry-leading connectivity** in a fully certified Wi-Fi MCU module supporting 2.4 GHz 802.11 b/g/n radio modes.
**Best-in-class WLAN functions** including:
