SDE6603-100M

Obsolete

Bourns Inc.

FIXED IND 10UH 1.1A 160 MOHM SMD

Search across all available documentation for this part.

Obsolete

Bourns Inc.

FIXED IND 10UH 1.1A 160 MOHM SMD

Technical Specifications

Parameters and characteristics for this part

Part	Shielding	Inductance Frequency - Test	Mounting Type	DC Resistance (DCR) [Max]	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]	Package / Case	Current Rating (Amps)	Operating Temperature [Min]	Operating Temperature [Max]	Inductance	Current - Saturation (Isat)	Material - Core	Type	Frequency - Self Resonant	Tolerance
Bourns Inc. SDE6603-330M	Unshielded	100 kHz	Surface Mount	510 mOhm	4.45 mm	0.175 in	6.6 mm	0.26 in	Nonstandard	600 mA	-25 °C	105 ░C	33 µH	580 mA	Ferrite	Drum Core Wirewound	15 MHz	20 %
Bourns Inc. SDE6603-681M	Unshielded	100 kHz	Surface Mount	9.2 Ohm	4.45 mm	0.175 in	6.6 mm	0.26 in	Nonstandard	120 mA	-25 °C	105 ░C	680 µH	140 mA	Ferrite	Drum Core Wirewound	3 MHz	20 %
Bourns Inc. SDE6603-100M	Unshielded	100 kHz	Surface Mount	160 mOhm	4.45 mm	0.175 in	6.6 mm	0.26 in	Nonstandard	1.1 A	-25 °C	105 ░C	10 µH	1.1 A	Ferrite	Drum Core Wirewound	35 MHz	20 %
Bourns Inc. SDE6603-331M	Unshielded	100 kHz	Surface Mount	3.8 Ohm	4.45 mm	0.175 in	6.6 mm	0.26 in	Nonstandard	160 mA	-25 °C	105 ░C	330 µH	180 mA	Ferrite	Drum Core Wirewound	5 MHz	20 %
Bourns Inc. SDE6603-2R2M	Unshielded	100 kHz	Surface Mount	70 mOhm	4.45 mm	0.175 in	6.6 mm	0.26 in	Nonstandard	2.4 A	-25 °C	105 ░C	2.2 µH	2.3 A	Ferrite	Drum Core Wirewound	90 MHz	20 %
Bourns Inc. SDE6603-221M	Unshielded	100 kHz	Surface Mount	3.11 Ohm	4.45 mm	0.175 in	6.6 mm	0.26 in	Nonstandard	0.2 A	-25 °C	105 ░C	220 µH	220 mA	Ferrite	Drum Core Wirewound	5.5 MHz	20 %

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

10 µH Unshielded Drum Core, Wirewound Inductor 1.1 A 160mOhm Max Nonstandard
