TEL 5-2423
ActiveTraco Power
DC DC CONVERTER +/-15V 6W
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
TEL 5-2423
ActiveTraco Power
DC DC CONVERTER +/-15V 6W
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | TEL 5-2423 |
|---|---|
| Applications | ITE (Commercial) |
| Efficiency | 86 % |
| Features | SCP |
| Mounting Type | Through Hole |
| Number of Outputs | 2 |
| Operating Temperature [Max] | 85 °C |
| Operating Temperature [Min] | -40 °C |
| Package / Case | 23-DIP Module |
| Package / Case | 8 Leads |
| Power (Watts) | 6 W |
| Size / Dimension [x] | 31.8 mm |
| Size / Dimension [x] | 1.25 " |
| Size / Dimension [y] | 0.8 in |
| Size / Dimension [y] | 20.3 mm |
| Size / Dimension [z] | 0.4 " |
| Size / Dimension [z] | 10.2 mm |
| Supplier Device Package | Module |
| Type | Isolated Module |
| Voltage - Input (Max) [Max] | 36 V |
| Voltage - Input (Min) [Min] | 18 V |
| Voltage - Isolation | 1.5 kV |
| Voltage - Output 1 | 15 V |
| Voltage - Output 2 | -15 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tube | 1 | $ 22.60 | |
| 10 | $ 15.88 | |||
Description
General part information
TEL 5 Series
Isolated Module DC DC Converter 2 Output 15V -15V 200mA, 200mA 18V - 36V Input
