5304UE 008500
ActiveBelden Inc.
CABLE 6COND 18AWG GRAY 500'
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
5304UE 008500
ActiveBelden Inc.
CABLE 6COND 18AWG GRAY 500'
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | 5304UE 008500 |
|---|---|
| Cable Type | Multi-Conductor |
| Conductor Insulation | Polypropylene (PP) |
| Conductor Material | Copper, Bare |
| Conductor Strand [custom] | 26 AWG |
| Conductor Strand [custom] | 7 |
| Features | Rip Cord |
| Jacket (Insulation) Diameter [diameter] | 0.22 in |
| Jacket (Insulation) Diameter [diameter] | 5.59 mm |
| Jacket (Insulation) Material | Poly-Vinyl Chloride (PVC), Riser |
| Jacket (Insulation) Thickness | 0.432 mm |
| Jacket (Insulation) Thickness | 0.017 in |
| Jacket Color | Gray |
| Length [x] | 500 ' |
| Length [x] | 152.4 m |
| Number of Conductors | 6 |
| Ratings | UL Style CMR |
| Usage | Sound, Security, Alarm |
| Wire Gauge | 18 AWG |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Spool | 1 | $ 294.87 | |
| 2 | $ 280.45 | |||
| 3 | $ 272.30 | |||
| 5 | $ 262.31 | |||
| 7 | $ 255.90 | |||
| 10 | $ 249.24 | |||
| 25 | $ 232.78 | |||
Description
General part information
5304UE Series
6 Conductor Multi-Conductor Cable Gray 18 AWG 500.0' (152.4m)
