966306-6
ActiveTE Connectivity AMP Connectors
CONN HEADER SMD 6POS 2.54MM
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
966306-6
ActiveTE Connectivity AMP Connectors
CONN HEADER SMD 6POS 2.54MM
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | 966306-6 |
|---|---|
| Connector Type | Breakaway, Header |
| Contact Finish - Mating | Gold |
| Contact Finish - Post | Tin |
| Contact Finish Thickness - Mating | 30 Áin |
| Contact Finish Thickness - Mating | 0.76 Ám |
| Contact Finish Thickness - Post | 3 µm |
| Contact Finish Thickness - Post | 118.1 µin |
| Contact Length - Mating | 0.228 in |
| Contact Length - Mating | 5.8 mm |
| Contact Material | Phosphor Bronze |
| Contact Shape | Square |
| Contact Type | Male Pin |
| Current Rating (Amps) | 5 A |
| Fastening Type | Push-Pull |
| Features | Pick and Place |
| Insulation Color | Black |
| Insulation Material | Polycyclohexylenedimethylene Terephthalate (PCT) |
| Mounting Type | Surface Mount |
| Number of Positions | 6 |
| Number of Positions Loaded | All |
| Number of Rows | 1 |
| Operating Temperature [Max] | 105 ░C |
| Operating Temperature [Min] | -65 ░C |
| Pitch - Mating | 0.1 in |
| Pitch - Mating | 2.54 mm |
| Shrouding | Unshrouded |
| Style | Board to Board, Cable |
| Termination | Solder |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tube | 2244 | $ 1.40 | |
966306 Series
CONN HEADER SMD 6POS 2.54MM
| Part | Termination | Fastening Type | Contact Length - Mating | Contact Length - Mating | Shrouding | Contact Material | Contact Finish Thickness - Post | Contact Finish Thickness - Post | Contact Type | Number of Positions Loaded | Contact Finish Thickness - Mating | Contact Finish Thickness - Mating | Contact Finish - Mating | Number of Rows | Features | Contact Finish - Post | Current Rating (Amps) | Style | Insulation Material | Pitch - Mating | Pitch - Mating | Number of Positions | Mounting Type | Contact Shape | Insulation Color | Operating Temperature [Min] | Operating Temperature [Max] | Connector Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
TE Connectivity AMP Connectors 966306-6 | Solder | Push-Pull | 0.228 in | 5.8 mm | Unshrouded | Phosphor Bronze | 3 µm | 118.1 µin | Male Pin | All | 30 Áin | 0.76 Ám | Gold | 1 | Pick and Place | Tin | 5 A | Board to Board, Cable | Polycyclohexylenedimethylene Terephthalate (PCT) | 0.1 in | 2.54 mm | 6 | Surface Mount | Square | Black | -65 ░C | 105 ░C | Breakaway, Header |
Description
General part information
966306 Series
Connector Header Surface Mount 6 position 0.100" (2.54mm)
