CB-04PMMP-LC7001

Active

Amphenol LTW

CERES, MIDDLE SIZE, 10A, 04 PINS, RECEPTACLE, CIRCULAR ROHS COMPLIANT: YES

Search across all available documentation for this part.

Active

Amphenol LTW

CERES, MIDDLE SIZE, 10A, 04 PINS, RECEPTACLE, CIRCULAR ROHS COMPLIANT: YES

Technical Specifications

Parameters and characteristics for this part

Specification	CB-04PMMP-LC7001

Color	Black
Connector Type	Receptacle, Male Pins
Contact Finish - Mating	Gold
Contact Material	Copper Alloy
Current Rating (Amps)	10 A
Fastening Type	Bayonet Lock
Ingress Protection	IP67 - Dust Tight, Waterproof
Insert Material	Polyamide (PA), Nylon, Glass Filled
Mounting Feature	Bulkhead - Front Side Nut
Mounting Type	Through Hole, Panel Mount
Number of Positions	4
Operating Temperature [Max]	105 ░C
Operating Temperature [Min]	-40 °C
Orientation	Keyed
Primary Material	Plastic
Shell Material	Nylon, Glass Filled, Polyamide (PA)
Shell Size - Insert	C
Shielding	Unshielded
Termination	Solder
Voltage Rating	250 VDC

Part	Mounting Feature	Primary Material	Shielding	Contact Finish - Mating	Color	Voltage Rating	Current Rating (Amps)	Orientation	Number of Positions	Insert Material	Shell Size - Insert	Fastening Type	Ingress Protection	Mounting Type	Connector Type	Shell Material	Operating Temperature [Min]	Operating Temperature [Max]	Termination	Contact Material
Amphenol LTW CB-04PMMP-LC7001	Bulkhead - Front Side Nut	Plastic	Unshielded	Gold	Black	250 VDC	10 A	Keyed	4	Polyamide (PA) Nylon Glass Filled	C	Bayonet Lock	IP67 - Dust Tight Waterproof	Panel Mount Through Hole	Male Pins Receptacle	Glass Filled Nylon Polyamide (PA)	-40 °C	105 ░C	Solder	Copper Alloy

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

4 Position Circular Connector Receptacle, Male Pins Solder
