4304M-102-101

Active

Bourns Inc.

RES ARRAY 2 RES 100 OHM 4SIP

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

4304M-102-101

Active

Bourns Inc.

RES ARRAY 2 RES 100 OHM 4SIP

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	4304M-102-101

Circuit Type	Isolated
Height - Seated (Max)	6.35 mm
Height - Seated (Max) [Max]	0.25 in
Mounting Type	Through Hole
Number of Pins	4
Number of Resistors	2
Operating Temperature [Max]	125 °C
Operating Temperature [Min]	-55 °C
Package / Case	4-SIP
Resistance (Ohms)	100 Ohms
Resistor-Ratio-Drift	50 ppm/°C
Size / Dimension [x]	9.75 mm
Size / Dimension [x]	0.384 "
Size / Dimension [y]	2.16 mm
Size / Dimension [y]	0.085 in
Supplier Device Package	4-SIP
Temperature Coefficient	100 ppm/°C
Tolerance	2 %

4304M Series

Part	Number of Pins	Power Per Element	Supplier Device Package	Temperature Coefficient	Circuit Type	Height - Seated (Max)	Height - Seated (Max) [Max]	Package / Case	Tolerance	Number of Resistors	Mounting Type	Resistance (Ohms)	Operating Temperature [Min]	Operating Temperature [Max]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [x]	Resistor-Ratio-Drift	Resistance (Ohms)
Bourns Inc. 4304M-101-102	4	250 mW	4-SIP	100 ppm/°C	Bussed	6.35 mm	0.25 in	4-SIP	2 %	3	Through Hole	1 kOhms	-55 °C	125 °C	9.75 mm	2.16 mm	0.085 in	0.384 "	50 ppm/°C
Bourns Inc. 4304M-102-104LF	4		4-SIP	100 ppm/°C	Isolated	6.35 mm	0.25 in	4-SIP	2 %	2	Through Hole	100 kOhms	-55 °C	125 °C	9.75 mm	2.16 mm	0.085 in	0.384 "	50 ppm/°C
Bourns Inc. 4304M-102-681LF	4		4-SIP	100 ppm/°C	Isolated	6.35 mm	0.25 in	4-SIP	2 %	2	Through Hole	680 Ohms	-55 °C	125 °C	9.75 mm	2.16 mm	0.085 in	0.384 "	50 ppm/°C
Bourns Inc. 4304M-101-221LF	4	250 mW	4-SIP	100 ppm/°C	Bussed	6.35 mm	0.25 in	4-SIP	2 %	3	Through Hole	220 Ohms	-55 °C	125 °C	9.75 mm	2.16 mm	0.085 in	0.384 "	50 ppm/°C
Bourns Inc. 4304M-104-161/111	4	250 mW	4-SIP	100 ppm/°C	Dual Terminator	6.35 mm	0.25 in	4-SIP	2 %	4	Through Hole	110 Ohms 160 Ohms	-55 °C	125 °C	9.75 mm	2.16 mm	0.085 in	0.384 "	50 ppm/°C
Bourns Inc. 4304M-102-222	4		4-SIP	100 ppm/°C	Isolated	6.35 mm	0.25 in	4-SIP	2 %	2	Through Hole	2.2 kOhms	-55 °C	125 °C	9.75 mm	2.16 mm	0.085 in	0.384 "	50 ppm/°C
Bourns Inc. 4304M-102-101	4		4-SIP	100 ppm/°C	Isolated	6.35 mm	0.25 in	4-SIP	2 %	2	Through Hole	100 Ohms	-55 °C	125 °C	9.75 mm	2.16 mm	0.085 in	0.384 "	50 ppm/°C
Bourns Inc. 4304M-104-121/191	4	250 mW	4-SIP	100 ppm/°C	Dual Terminator	6.35 mm	0.25 in	4-SIP	2 %	4	Through Hole		-55 °C	125 °C	9.75 mm	2.16 mm	0.085 in	0.384 "	50 ppm/°C
Bourns Inc. 4304M-102-221LF	4		4-SIP	100 ppm/°C	Isolated	6.35 mm	0.25 in	4-SIP	2 %	2	Through Hole	220 Ohms	-55 °C	125 °C	9.75 mm	2.16 mm	0.085 in	0.384 "	50 ppm/°C
Bourns Inc. 4304M-101-103	4	250 mW	4-SIP	100 ppm/°C	Bussed	6.35 mm	0.25 in	4-SIP	2 %	3	Through Hole		-55 °C	125 °C	9.75 mm	2.16 mm	0.085 in	0.384 "	50 ppm/°C	10k

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Tube	2000	$ 1.86

Description

General part information

4304M Series

100 Ohm ±2% 400mW Power Per Element Isolated 2 Resistor Network/Array ±100ppm/°C 4-SIP
