Technical Specifications
Parameters and characteristics for this part
| Specification | 1875GB 0051000 |
|---|---|
| Cable Type | Multi-Pair, Cat6 |
| Conductor Insulation | Polyolefin (PO) |
| Conductor Material | Copper, Tinned |
| Conductor Strand [custom] | 32 AWG |
| Conductor Strand [custom] | 7 |
| Jacket (Insulation) Diameter [diameter] | 0.365 in |
| Jacket (Insulation) Diameter [diameter] | 9.27 mm |
| Jacket (Insulation) Material | Poly-Vinyl Chloride (PVC), Riser |
| Jacket Color | Green |
| Length | 1000 ft |
| Length | 304.8 m |
| Number of Conductors | 8 |
| Ratings | UL Style CMR |
| Usage | Video, Ethernet, LAN |
| Voltage | 300 V |
| Wire Gauge | 24 AWG |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
Description
General part information
1875GB Series
8 (4 Pair) Conductor Multi-Pair, Cat6 Cable Green 24 AWG 1000.0' (304.8m)
Documents
Technical documentation and resources
