KNW013A0A41-88Z
ActiveOmniOn Power™
DC DC CONVERTER 5V 65W
KNW013A0A41-88Z
ActiveOmniOn Power™
DC DC CONVERTER 5V 65W
Description
General part information
KNW013 Series
Isolated Module DC DC Converter 1 Output 5V 13A 36V - 75V Input
Technical Specifications
Parameters and characteristics for this part
| Specification | KNW013A0A41-88Z |
|---|---|
| Applications | ITE (Commercial) |
| Control Features | Enable, Active Low |
| Current - Output (Max) | 13 A |
| Efficiency | 91 % |
| Features | UVLO, OCP, Remote On/Off, OVP, OTP |
| Mounting Type | Through Hole |
| Number of Outputs | 1 |
| Operating Temperature (Max) | 85 °C |
| Operating Temperature (Min) | -40 °C |
| Package / Case | 8-DIP Module |
| Power (Watts) | 65 W |
| Size / Dimension Height | 0.4 in |
| Size / Dimension Length | 1.3 in |
| Size / Dimension Width | 0.9 in |
| Type | Isolated Module |
| Voltage - Input (Max) | 75 V |
| Voltage - Input (Min) | 36 V |
| Voltage - Isolation | 2.25 kV |
| Voltage - Output 1 | 5 V |
