General part information
The STTH8R06, which uses ST Turbo 2 600 V technology, is specially suited as boost diode in continuous mode power factor corrections and hard switching conditions.
Parameters and characteristics commom to parts in this series
| Specification | STTH8R06G-TR | STTH8R06 Series |
|---|---|---|
| Current - Average Rectified (Io) | 8 A | 8 A |
| Current - Reverse Leakage @ Vr | 30 µA | 30 µA |
| Mounting Type | Surface Mount | Surface Mount, Through Hole |
| Operating Temperature - Junction [Max] | 175 °C | 175 °C |
| Package / Case | D2PAK (2 Leads + Tab), TO-263AB, TO-263-3 | D2PAK (2 Leads + Tab), TO-263AB, TO-263-3, TO-220-2 Full Pack |
| Reverse Recovery Time (trr) | 45 ns | 45 ns |
| Speed | 200 mA, 500 ns | 200 - 500 mA |
| Supplier Device Package | D2PAK | D2PAK |
| Technology | Standard | Standard |
| Voltage - DC Reverse (Vr) (Max) [Max] | 600 V | 600 V |
600 V, 8 A Turbo 2 Ultrafast Diode
| Part | Speed | Reverse Recovery Time (trr) | Voltage - DC Reverse (Vr) (Max) [Max] | Operating Temperature - Junction [Max] | Current - Average Rectified (Io) | Mounting Type | Package / Case | Supplier Device Package | Current - Reverse Leakage @ Vr | Technology |
|---|---|---|---|---|---|---|---|---|---|---|
STMicroelectronics STTH8R06G-TR | 200 mA, 500 ns | 45 ns | 600 V | 175 °C | 8 A | Surface Mount | D2PAK (2 Leads + Tab), TO-263-3, TO-263AB | D2PAK | 30 µA | Standard |
STMicroelectronics STTH8R06FP | 200 mA, 500 ns | 45 ns | 600 V | 175 °C | 8 A | Through Hole | TO-220-2 Full Pack | 30 µA | Standard |
