CD74AC32E

Obsolete

Harris Corporation

IC GATE OR 4CH 2-INP 14DIP

Search across all available documentation for this part.

Obsolete

Harris Corporation

IC GATE OR 4CH 2-INP 14DIP

Technical Specifications

Parameters and characteristics commom to parts in this series

Specification	CD74AC32E	74AC32 Series

Current - Output High, Low	24 mA	24 mA
Current - Quiescent (Max) [Max]	4 µA	4 µA
Input Logic Level - High [Max]	3.85 V	3.85 V
Input Logic Level - High [Min]	1.2 V	1.2 V
Input Logic Level - Low [Max]	1.65 V	1.65 V
Input Logic Level - Low [Min]	0.3 V	0.3 V
Logic Type	OR Gate	OR Gate
Max Propagation Delay @ V, Max CL	9.5 ns	9.5 ns
Mounting Type	Through Hole	Surface Mount, Through Hole
Number of Circuits	4	4
Number of Inputs	2	2
Operating Temperature [Max]	125 °C	125 °C
Operating Temperature [Min]	-55 °C	-55 °C
Package / Case	14-DIP	14-SOIC, 14-DIP
Package / Case [x]	0.3 "	0.154 - 0.3 in
Package / Case [y]	7.62 mm	3.9 - 7.62 mm
Voltage - Supply [Max]	5.5 V	5.5 V
Voltage - Supply [Min]	1.5 V	1.5 V

IC GATE OR 4CH 2-INP 14SOIC

Part	Mounting Type	Current - Output High, Low	Input Logic Level - High [Max]	Input Logic Level - High [Min]	Number of Inputs	Voltage - Supply [Max]	Voltage - Supply [Min]	Input Logic Level - Low [Min]	Input Logic Level - Low [Max]	Logic Type	Max Propagation Delay @ V, Max CL	Number of Circuits	Current - Quiescent (Max) [Max]	Operating Temperature [Min]	Operating Temperature [Max]	Package / Case [x]	Package / Case [y]	Package / Case
Harris Corporation CD74AC32M	Surface Mount	24 mA	3.85 V	1.2 V	2	5.5 V	1.5 V	0.3 V	1.65 V	OR Gate	9.5 ns	4	4 µA	-55 °C	125 °C	0.154 in	3.9 mm	14-SOIC
Harris Corporation CD74AC32E	Through Hole	24 mA	3.85 V	1.2 V	2	5.5 V	1.5 V	0.3 V	1.65 V	OR Gate	9.5 ns	4	4 µA	-55 °C	125 °C	0.3 "	7.62 mm	14-DIP
