3-1393240-8

Active

TE Connectivity Potter & Brumfield Relays

RT334F05

Search across all available documentation for this part.

Active

TE Connectivity Potter & Brumfield Relays

RT334F05

Technical Specifications

Parameters and characteristics for this part

RT334F05

Part	Load - Max Switching	Approval Agency	Termination Style	Must Release Voltage	Contact Form	Release Time	Coil Resistance	Operating Temperature [Max]	Operating Temperature [Min]	Must Operate Voltage	Coil Insulation	Relay Type	Coil Voltage	Coil Type	Mounting Type	Contact Rating (Current)	Seal Rating	Contact Material	Coil Current	Operate Time	Switching Voltage [Max]
TE Connectivity Potter & Brumfield Relays 3-1393240-8	6400 VA	CQC, CSA, cURus, VDE	PC Pin	0.5 VDC	SPST-NO (1 Form A)	6 ms	62 Ohms	85 °C	-40 °C	3.5 VDC	Class F	General Purpose	5 VDC	Latching, Dual Coil	Through Hole	16 A	Sealed - Flux Protection	Silver Nickel (AgNi)	80.6 mA	8 ms	400 VAC

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Tube	1500	$ 4.45

General part information

General Purpose Relay SPST-NO (1 Form A) 5VDC Coil Through Hole
