AM1DS-0305SH30-NZ

Active

aimtec

DC DC CONVERTER 5V 1W

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

AM1DS-0305SH30-NZ

Active

aimtec

DC DC CONVERTER 5V 1W

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	AM1DS-0305SH30-NZ

Applications	ITE (Commercial)
Current - Output (Max) [Max]	200 mA
Efficiency	78 %
Mounting Type	Through Hole
Number of Outputs	1
Operating Temperature [Max]	105 ░C
Operating Temperature [Min]	-40 °C
Size / Dimension [x]	19.5 mm
Size / Dimension [x]	0.77 in
Size / Dimension [y]	6 mm
Size / Dimension [y]	0.24 "
Size / Dimension [z]	0.38 in
Size / Dimension [z]	9.6 mm
Type	Isolated Module
Voltage - Input (Max) [Max]	3.6 V
Voltage - Input (Min) [Min]	3 V
Voltage - Isolation	3000 V
Voltage - Output 1	5 V

AM1DS Series

Part	Voltage - Isolation	Number of Outputs	Voltage - Input (Max) [Max]	Operating Temperature [Max]	Operating Temperature [Min]	Voltage - Output 1 [Max]	Voltage - Output 1 [Min]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [y]	Mounting Type	Efficiency	Voltage - Input (Min) [Min]	Applications	Type	Voltage - Output 2	Current - Output (Max)	Current - Output (Max)	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [x]	Approval Agency	Current - Output (Max) [Max]	Voltage - Output 1	Package / Case	Supplier Device Package
aimtec AM1DS-0515DH60Z	6000 V	2	5.5 V	85 °C	-40 °C	15 V	-15 V	0.76 "	0.39 in	10 mm	19.5 mm	6 mm	0.24 "	Through Hole	71 %	4.5 V	ITE (Commercial)	Isolated Module	-15 V	33.33 mA	33.33 mA
aimtec AM1DS-1215DH52Z	5.2 kV	2	13.2 V	85 °C	-40 °C	15 V	-15 V			0.39 in	0.77 "	0.24 in		Through Hole	76 %	10.8 V	ITE (Commercial)	Isolated Module	-15 V	33.33 mA	33.33 mA	6 mm	10 mm	19.5 mm
aimtec AM1DS-1212DH52Z	5.2 kV	2	13.2 V	85 °C	-40 °C	12 V	-12 V	0.76 "	0.39 in	10 mm	19.5 mm	6 mm	0.24 "	Through Hole	76 %	10.8 V	ITE (Commercial)	Isolated Module	-12 V	41.67 mA	41.67 mA
aimtec AM1DS-0515DH30JZ	3000 V	2	5.5 V	105 ░C	-40 °C	15 V	-15 V	0.77 in	0.4 "	10.2 mm	19.7 mm	6 mm	0.24 "	Through Hole	83 %	4.5 V	ITE (Commercial)	Isolated Module	-15 V		34 mA				cULus cURus
aimtec AM1DS-1205SH30-NZ	3000 V	1	13.2 V	105 C	-40 °C			0.77 in	0.37 in	9.3 mm	19.5 mm	6 mm	0.24 "	Through Hole	80 %	10.8 V	ITE (Commercial)	Isolated Module								200 mA	5 V	7-SIP Module 6 Leads	7-SIP
aimtec AM1DS-1215SZ	1000 V	1	13.2 V	85 °C	-40 °C					0.39 in	0.77 "	0.24 in		Through Hole	75 %	10.8 V	ITE (Commercial)	Isolated Module				6 mm	10 mm	19.5 mm		66.7 mA	15 V
aimtec AM1DS-0305SH30-NZ	3000 V	1	3.6 V	105 ░C	-40 °C			0.77 in	0.38 in	9.6 mm	19.5 mm	6 mm	0.24 "	Through Hole	78 %	3 V	ITE (Commercial)	Isolated Module								200 mA	5 V
aimtec AM1DS-0515SH30JZ	3000 V	1	5.5 V	105 ░C	-40 °C			0.77 in	0.4 "	10.2 mm	19.7 mm	6 mm	0.24 "	Through Hole	83 %	4.5 V	ITE (Commercial)	Isolated Module								67 mA	15 V
aimtec AM1DS-1205DH52Z	5.2 kV	2	13.2 V	85 °C	-40 °C	5 V	-5 V	0.76 "	0.39 in	10 mm	19.5 mm	6 mm	0.24 "	Through Hole	73 %	10.8 V	ITE (Commercial)	Isolated Module	-5 V	100 mA	100 mA
aimtec AM1DS-0515DH40Z	4000 V	2	5.5 V	85 °C	-40 °C	15 V	-15 V	0.76 "	0.39 in	10 mm	19.5 mm	6 mm	0.24 "	Through Hole	71 %	4.5 V	ITE (Commercial)	Isolated Module	-15 V	33.33 mA	33.33 mA
