20VS6
ActiveTE Connectivity Raychem Cable Protection
LINE FILTER 120V/250VAC 20A CHAS
Deep-Dive with AI
Search across all available documentation for this part.
20VS6
ActiveTE Connectivity Raychem Cable Protection
LINE FILTER 120V/250VAC 20A CHAS
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | 20VS6 |
|---|---|
| Applications | General Purpose |
| Approval Agency | VDE, CSA, UR |
| Configuration | Two Stage |
| Current | 20 A |
| Filter Type | Single Phase |
| Frequency - Operating [Max] | 60 Hz |
| Frequency - Operating [Min] | 50 Hz |
| Inductance | 960 µH |
| Mounting Type | Chassis Mount |
| Operating Temperature [Max] | 40 °C |
| Operating Temperature [Min] | -10 °C |
| Termination Style | Threaded Post (8-32) |
| Voltage - Rated AC | 120 V, 250 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 72.83 | |
| 12 | $ 70.40 | |||
| 28 | $ 67.97 | |||
| 52 | $ 65.54 | |||
| 100 | $ 60.09 | |||
Description
General part information
20V Series
Single Phase EMC/EMI Line Filter 20 A 120V, 250V 50/60Hz Two Stage Threaded Post (8-32)
