10142632-004LF

Active

Amphenol ICC (FCI)

CONN RCPT HSG 4POS 1.27MM

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

10142632-004LF

Active

Amphenol ICC (FCI)

CONN RCPT HSG 4POS 1.27MM

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	10142632-004LF

Color	Black
Connector Type	Receptacle
Contact Termination	Crimp
Contact Type	Female Socket
Features	Terminal Position Lock (TPA)
Insulation Material	Thermoplastic
Mounting Type	Free Hanging (In-Line)
Note	Contacts Not Included
Number of Positions	4
Number of Rows	2
Operating Temperature [Max]	130 °C
Operating Temperature [Min]	-40 °C
Pitch [x]	0.05 in
Pitch [x]	1.27 mm
Row Spacing [custom]	2.43 mm
Row Spacing [custom]	0.096 in

10142632 Series

Part	Color	Operating Temperature [Min]	Operating Temperature [Max]	Connector Type	Contact Type	Insulation Material	Mounting Type	Contact Termination	Number of Positions	Number of Rows	Pitch [x]	Pitch [x]	Features	Note	Row Spacing [custom]	Row Spacing [custom]
Amphenol ICC (FCI) 10142632-011LF	Black	-40 °C	130 °C	Receptacle	Female Socket	Thermoplastic	Free Hanging (In-Line)	Crimp	11	2	0.05 in	1.27 mm	Terminal Position Lock (TPA)	Contacts Not Included	2.43 mm	0.096 in
Amphenol ICC (FCI) 10142632-012LF	Black	-40 °C	130 °C	Receptacle	Female Socket	Thermoplastic	Free Hanging (In-Line)	Crimp	12	2	0.05 in	1.27 mm	Terminal Position Lock (TPA)	Contacts Not Included	2.43 mm	0.096 in
Amphenol ICC (FCI) 10142632-002LF	Black	-40 °C	130 °C	Receptacle	Female Socket	Thermoplastic	Free Hanging (In-Line)	Crimp	2	2	0.05 in	1.27 mm	Terminal Position Lock (TPA)	Contacts Not Included	2.43 mm	0.096 in
Amphenol ICC (FCI) 10142632-004LF	Black	-40 °C	130 °C	Receptacle	Female Socket	Thermoplastic	Free Hanging (In-Line)	Crimp	4	2	0.05 in	1.27 mm	Terminal Position Lock (TPA)	Contacts Not Included	2.43 mm	0.096 in
Amphenol ICC (FCI) 10142632-007LF	Black	-40 °C	130 °C	Receptacle	Female Socket	Thermoplastic	Free Hanging (In-Line)	Crimp	7	2	0.05 in	1.27 mm	Terminal Position Lock (TPA)	Contacts Not Included	2.43 mm	0.096 in
Amphenol ICC (FCI) 10142632-006LF	Black	-40 °C	130 °C	Receptacle	Female Socket	Thermoplastic	Free Hanging (In-Line)	Crimp	6	2	0.05 in	1.27 mm	Terminal Position Lock (TPA)	Contacts Not Included	2.43 mm	0.096 in
Amphenol ICC (FCI) 10142632-013LF	Black	-40 °C	130 °C	Receptacle	Female Socket	Thermoplastic	Free Hanging (In-Line)	Crimp	13	2	0.05 in	1.27 mm	Terminal Position Lock (TPA)	Contacts Not Included	2.43 mm	0.096 in

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	1	$ 0.87
		10	$ 0.66
		25	$ 0.59
		50	$ 0.58
		100	$ 0.43

Description

General part information

10142632 Series

4 Rectangular Connectors - Housings Receptacle Black 0.050" (1.27mm)
