23SW-00150400-S10B-US

Obsolete

IDEAL POWER

AC/DC DESKTOP ADAPTER 15V 60W

Search across all available documentation for this part.

Obsolete

IDEAL POWER

AC/DC DESKTOP ADAPTER 15V 60W

Technical Specifications

Parameters and characteristics for this part

AC/DC DESKTOP ADAPTER 15V 60W

Part	Operating Temperature [Max]	Operating Temperature [Min]	Region Utilized	Voltage - Input [Min]	Voltage - Input [Max]	Input Type	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Input Connector	Power (Watts)	Current - Output (Max) [Max]	Standard Number	Output Connector	Output Connector [diameter]	Output Connector [z]	Approval Agency	Efficiency	Polarization	No Load Power Consumption	Voltage - Output	Form	Applications	Cord Length	Cord Length
IDEAL POWER 23SW-00150400-S10B-US	40 °C	0 °C	International	90 VAC	264 VAC	Cord	2.8 in	1.35 "	34.2 mm	106.4 mm	71.1 mm	4.19 "	IEC 320-C8	60 W	4 A	60950-1	Barrel Plug	2.1 mm, 5.5 mm	12 mm	CE, cUL, FCC, GS, TUV, UL	89 %	Positive Center	100 mW	15 VDC	Desktop (Class II)	ITE (Commercial)	70.9 in	1.8 m

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

15V 60 W AC/DC External Desktop (Class II) Adapter Cord (Sold Separately) Input
