Specification	TC040350BB00G

Color	Green
Features	Interlocking (Side)
Mating Orientation	Horizontal with Board
Mounting Type	Through Hole
Number of Levels	1
Positions Per Level	4
Wire Termination	Wire Guard, Screw, Leaf Spring

tc Series

Part	Housing Material	Screw Thread	Torque - Screw	Operating Temperature (Min)	Operating Temperature (Max)	Screw Plating	Screw Material	Clamp Material - Plating	Current	Pitch	Number of Levels	Mating Orientation	Color	Wire Termination	Voltage	Positions Per Level	Wire Gauge (AWG) (Min)	Wire Gauge (AWG) (Max)	Mounting Type	Features	Contact Material	Plating
McGill Microwave Systems TC0803620000G	Thermoplastic	M2.6	0.3 Nm	-40 °C	115 °C	Zinc Plated	Steel	Steel Stainless	15 A	0.197 in	1	Horizontal with Board	Blue	Leaf Spring Screw Wire Guard	300 V	8	14 AWG	22 AWG	Through Hole	Interlocking (Side)
McGill Microwave Systems TC0403620000G	Thermoplastic	M2.6	0.3 Nm	-40 °C	115 °C	Zinc Plated	Steel	Steel Stainless	15 A	0.197 in	1	Horizontal with Board	Blue	Leaf Spring Screw Wire Guard	300 V	4	14 AWG	22 AWG	Through Hole	Interlocking (Side)
McGill Microwave Systems TC1023620000G	Thermoplastic	M2.6	0.3 Nm	-40 °C	115 °C	Zinc Plated	Steel	Steel Stainless	15 A	5.08 mm	1	Horizontal with Board	Blue	Leaf Spring Screw Wire Guard	300 V	10	14 AWG	22 AWG	Through Hole	Interlocking (Side)
McGill Microwave Systems TC040350BB00G											1	Horizontal with Board	Green	Leaf Spring Screw Wire Guard		4			Through Hole	Interlocking (Side)
McGill Microwave Systems TC2203620000G									15 A	0.197 in	1	Horizontal with Board	Blue	Leaf Spring Screw Wire Guard	300 V	22	14 AWG	22 AWG	Through Hole	Interlocking (Side)
McGill Microwave Systems TC0203800000G	Thermoplastic	M2.6	0.3 Nm	-40 °C	115 °C	Zinc Plated	Steel	Steel Stainless	15 A	0.197 in	1	Horizontal with Board	Gray	Leaf Spring Screw Wire Guard	300 V	2	14 AWG	22 AWG	Through Hole	Interlocking (Side)	Brass	Tin Plated
McGill Microwave Systems TC220362A500G	Thermoplastic	M2.6	0.3 Nm	-40 °C	115 °C	Zinc Plated	Steel	Steel Stainless	15 A	0.197 in	1	Horizontal with Board	Blue	Leaf Spring Screw Wire Guard	300 V	22	14 AWG	22 AWG	Through Hole	Interlocking (Side)
McGill Microwave Systems TC240362A500G	Thermoplastic	M2.6	0.3 Nm	-40 °C	115 °C	Zinc Plated	Steel	Steel Stainless	15 A	0.197 in	1	Horizontal with Board	Blue	Leaf Spring Screw Wire Guard	300 V	24	14 AWG	22 AWG	Through Hole	Interlocking (Side)
McGill Microwave Systems TC1003620000G									15 A	0.197 in	1	Horizontal with Board	Blue	Leaf Spring Screw Wire Guard	300 V	10	14 AWG	22 AWG	Through Hole	Interlocking (Side)
McGill Microwave Systems TC1323620000G	Thermoplastic	M2.6	0.3 Nm	-40 °C	115 °C	Zinc Plated	Steel	Steel Stainless	15 A	5.08 mm	1	Horizontal with Board	Blue	Leaf Spring Screw Wire Guard	300 V	13	14 AWG	22 AWG	Through Hole	Interlocking (Side)

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Create a free account to access distributor pricing data.

CAD

3D models and CAD resources for this part

Documents

Technical documentation and resources

TC040350BB00G | Datasheet

TC5.0A.pdf
