B1360W

Active

TE Connectivity Raychem Cable Protection

WHIP,MC,1/2,136-174 MHZ 153,0,CH,GP,

Search across all available documentation for this part.

Active

TE Connectivity Raychem Cable Protection

WHIP,MC,1/2,136-174 MHZ 153,0,CH,GP,

Technical Specifications

Parameters and characteristics for this part

Part	VSWR	Height (Max)	Height (Max) [Max]	Ingress Protection	Frequency Group	Power - Max [Max]	Termination	Frequency Range [Min]	Frequency Range [Max]	Frequency (Center/Band)	Antenna Type	Mounting Type	Gain	Number of Bands
TE Connectivity Raychem Cable Protection B1360W	2	495.3 mm	19.5 in	IP67	VHF	100 W	NMO	136 MHz	174 MHz	155 MHz	Whip Straight	Magnetic Trunk	4 dBi	1
TE Connectivity Raychem Cable Protection B1360WS	2	495.3 mm	19.5 in	IP67	VHF	100 W	NMO	136 MHz	174 MHz	155 MHz	Whip Straight	Magnetic Trunk	4 dBi	1

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	8	$ 71.35

General part information

Whip Antenna, Single Band, VHF / Vehicular, External Mount, Stud/Screw/Lug Mount, NMO, Omnidirectional, Single Port, 0 < 3 dBi Peak Gain
