T1549030000-000 - T1549030000-000

T1549030000-000

Active
TE Connectivity AMP Connectors

H3A-MAGS

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsHDC H3A metal series IP65 Housing & Hood product specDatasheet+1
T1549030000-000 - T1549030000-000

T1549030000-000

Active
TE Connectivity AMP Connectors

H3A-MAGS

Deep-Dive with AI

DocumentsHDC H3A metal series IP65 Housing & Hood product specDatasheet+1

Technical Specifications

Parameters and characteristics commom to parts in this series

SpecificationT1549030000-000T154 Series
Connector TypeBase - Panel Mount 90°Base - Panel Mount 90°
Housing ColorGrayGray
Housing FinishPowder CoatedPowder Coated, Nickel
Housing MaterialZinc Alloy, Die CastZinc Alloy, Die Cast
Ingress ProtectionIP65 - Dust Tight, Water ResistantIP65 - Dust Tight, Water Resistant
Lock LocationLocking Clip (1) on Base BottomLocking Clip (1) on Base Bottom
Operating Temperature [Max]125 °C125 °C
Operating Temperature [Min]-40 °C-40 °C
SizeH3AH3A
StyleSide EntrySide Entry

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

DistributorPackageQuantity$
DigikeyBulk 1$ 8.63
10$ 7.15
25$ 6.63
50$ 6.27
100$ 5.93
250$ 5.50
500$ 5.20
1000$ 4.92

T154 Series

H3A-MAGS

PartHousing FinishSizeHousing ColorOperating Temperature [Max]Operating Temperature [Min]Ingress ProtectionHousing MaterialStyleConnector TypeLock Location
TE Connectivity AMP Connectors
T1549030000-000
Powder Coated
H3A
Gray
125 °C
-40 °C
IP65 - Dust Tight, Water Resistant
Zinc Alloy, Die Cast
Side Entry
Base - Panel Mount 90°
Locking Clip (1) on Base Bottom
TE Connectivity AMP Connectors
T1546033000-000
Nickel
H3A
125 °C
-40 °C
IP65 - Dust Tight, Water Resistant
Zinc Alloy, Die Cast
Side Entry
Base - Panel Mount 90°
Locking Clip (1) on Base Bottom

Description

General part information

T154 Series

Base - Panel Mount 90° Connector Side Entry H3A IP65 - Dust Tight, Water Resistant
