1-1102305-2
ActiveTE Connectivity AMP Connectors
CONN BASE BOTTOM ENTRY SZ6
Deep-Dive with AI
Search across all available documentation for this part.
1-1102305-2
ActiveTE Connectivity AMP Connectors
CONN BASE BOTTOM ENTRY SZ6
Deep-Dive with AI
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | 1-1102305-2 | 1102305 Series |
|---|---|---|
| Connector Type | Base - Panel Mount | Base - Panel Mount |
| Features | Cover | Cover |
| Housing Color | Gray | Gray, Black |
| Housing Finish | Powder Coated | Powder Coated, Aluminum Oxide |
| Housing Material | Aluminum Alloy, Die Cast | Aluminum Alloy, Die Cast |
| Ingress Protection | IP65 - Dust Tight, Water Resistant | IP65 - Dust Tight, Water Resistant |
| Lock Location | Locking Clip (1) on Base Bottom | Locking Clip (1) on Base Bottom |
| Operating Temperature | - | -40 °C |
| Operating Temperature | - | 80 C |
| Size | 6 | 6 |
| Size / Dimension [x] | 4.449 " | 4.449 " |
| Size / Dimension [x] | 113 mm | 113 mm |
| Size / Dimension [y] | 43.5 mm | 43.5 mm |
| Size / Dimension [y] | 1.713 in | 1.713 in |
| Size / Dimension [z] | 28.5 mm | 28.5 mm |
| Size / Dimension [z] | 1.122 in | 1.122 in |
| Style | Bottom Entry | Bottom Entry |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 40 | $ 77.62 | |
1102305 Series
CONN BASE BOTTOM ENTRY SZ6
| Part | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [z] | Size / Dimension [z] | Size / Dimension [y] | Size | Housing Finish | Lock Location | Housing Material | Housing Color | Ingress Protection | Features | Style | Connector Type | Operating Temperature [Min] | Operating Temperature [Max] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
TE Connectivity AMP Connectors 1-1102305-2 | 4.449 " | 43.5 mm | 113 mm | 28.5 mm | 1.122 in | 1.713 in | 6 | Powder Coated | Locking Clip (1) on Base Bottom | Aluminum Alloy, Die Cast | Gray | IP65 - Dust Tight, Water Resistant | Cover | Bottom Entry | Base - Panel Mount | ||
TE Connectivity AMP Connectors 2-1102305-2 | 4.449 " | 43.5 mm | 113 mm | 28.5 mm | 1.122 in | 1.713 in | 6 | Aluminum Oxide | Locking Clip (1) on Base Bottom | Aluminum Alloy, Die Cast | Black | IP65 - Dust Tight, Water Resistant | Cover | Bottom Entry | Base - Panel Mount | -40 °C | 80 C |
Description
General part information
1102305 Series
Base - Panel Mount Connector Bottom Entry 6 IP65 - Dust Tight, Water Resistant
