82742 8771000

Active

Belden Inc.

MULTI-PAIR 6COND 22AWG NAT

Search across all available documentation for this part.

Active

Belden Inc.

MULTI-PAIR 6COND 22AWG NAT

Technical Specifications

Parameters and characteristics for this part

Specification	82742 8771000

Cable Type	Multi-Pair
Conductor Insulation	Fluorinated Ethylene-Propylene (FEP)
Conductor Material	Copper, Tinned
Conductor Strand [custom]	7
Conductor Strand [custom]	30 AWG
Jacket (Insulation) Diameter [diameter]	4.85 mm
Jacket (Insulation) Diameter [diameter]	0.191 in
Jacket (Insulation) Material	Low Smoke Poly-Vinyl Chloride (LSPVC), Plenum
Jacket (Insulation) Thickness	0.356 mm
Jacket (Insulation) Thickness	0.014 in
Jacket Color	Natural
Length	1000 ft
Length	304.8 m
Number of Conductors	6
Operating Temperature [Max]	60 °C
Operating Temperature [Min]	0 °C
Usage	Audio, Instrumentation, Control
Voltage	300 V
Wire Gauge	22 AWG

Part	Wire Gauge	Conductor Material	Length	Length	Jacket (Insulation) Thickness	Jacket (Insulation) Thickness	Operating Temperature [Max]	Operating Temperature [Min]	Conductor Strand [custom]	Conductor Strand [custom]	Conductor Insulation	Jacket Color	Voltage	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Cable Type	Usage	Jacket (Insulation) Material	Number of Conductors
Belden Inc. 82742 8771000	22 AWG	Copper Tinned	1000 ft	304.8 m	0.356 mm	0.014 in	60 °C	0 °C	7	30 AWG	Fluorinated Ethylene-Propylene (FEP)	Natural	300 V	4.85 mm	0.191 in	Multi-Pair	Audio Control Instrumentation	Low Smoke Poly-Vinyl Chloride (LSPVC) Plenum	6

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Spool	1000	$ 6.38

General part information

6 (3 Pair Twisted) Conductor Multi-Pair Cable Natural 22 AWG 1000.0' (304.8m)
