EO0301000000G

Active

AMPHENOL ANYTEK

TERM BLOCK PLUG 3POS 90DEG 5MM

Deep-Dive with AI

Search across all available documentation for this part.

EO0301000000G

Active

AMPHENOL ANYTEK

TERM BLOCK PLUG 3POS 90DEG 5MM

Deep-Dive with AI

Specifications Pricing Series Description Documents

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	1	$ 1.63
		10	$ 0.92
		25	$ 0.78
		50	$ 0.70
		100	$ 0.64
		250	$ 0.59
		500	$ 0.56
		2000	$ 0.52
		6000	$ 0.50

Description

General part information

EO Series

3 Position Terminal Block Plug for Unshrouded Header 0.197" (5.00mm) 90° Free Hanging (In-Line)

Documents

Technical documentation and resources

No documents available

Technical Specifications

Parameters and characteristics commom to parts in this series

Specification	EO0301000000G	EO Series

Color	Black	Black
Contact Material	Phosphor Bronze	Phosphor Bronze
Contact Mating Finish	Tin	Tin
Housing Material	Thermoplastic	Thermoplastic
Insulation Height	-	15.9 mm
Insulation Height	-	0.626 in
Insulation Height [z]	0.587 in	0.587 in
Insulation Height [z]	14.91 mm	14.91 mm
Material Flammability Rating	UL94 V-0	UL94 V-0
Mounting Type	Free Hanging (In-Line)	Free Hanging (In-Line)
Number of Levels	1	1
Number of Positions	-	2 - 23
Number of Positions	-	16
Operating Temperature [Max]	115 °C	115 °C
Operating Temperature [Min]	-40 °C	-40 °C
Pitch [x]	5 mm	5 mm
Pitch [x]	0.197 in	0.197 in
Plug Wire Entry	90 °	90 °
Positions Per Level	3	2 - 23
Screw Size	M3	M3
Termination Style	Screw	Screw
Torque - Screw	0.51 Nm	0.51 Nm
Torque - Screw	4.5 Lb-In	4.5 Lb-In
Type	Plug for Unshrouded Header	Plug for Unshrouded Header
Voltage - UL	300 V	300 V
Wire Gauge or Range - AWG [Max]	28 AWG	28 AWG
Wire Gauge or Range - AWG [Min]	12 AWG	12 AWG
Wire Strip Length [Max]	6 mm	6 mm
Wire Strip Length [Min]	5 mm	5 mm

EO Series

TERM BLOCK PLUG 3POS 90DEG 5MM

Part	Pitch [x]	Pitch [x]	Termination Style	Screw Size	Type	Operating Temperature [Min]	Operating Temperature [Max]	Voltage - UL	Contact Material	Insulation Height	Insulation Height	Positions Per Level	Color	Plug Wire Entry	Material Flammability Rating	Wire Strip Length [Min]	Wire Strip Length [Max]	Wire Gauge or Range - AWG [Max]	Wire Gauge or Range - AWG [Min]	Torque - Screw	Torque - Screw	Mounting Type	Housing Material	Contact Mating Finish	Number of Levels	Number of Positions	Insulation Height [z]	Insulation Height [z]
AMPHENOL ANYTEK EO030102A000G	5 mm	0.197 in	Screw	M3	Plug for Unshrouded Header	-40 °C	115 °C	300 V	Phosphor Bronze	15.9 mm	0.626 in	3	Black	90 °	UL94 V-0	5 mm	6 mm	28 AWG	12 AWG	0.51 Nm	4.5 Lb-In	Free Hanging (In-Line)	Thermoplastic	Tin	1
AMPHENOL ANYTEK EO1101000000G	5 mm	0.197 in	Screw	M3	Plug for Unshrouded Header	-40 °C	115 °C	300 V	Phosphor Bronze			11	Black	90 °	UL94 V-0	5 mm	6 mm	28 AWG	12 AWG	0.51 Nm	4.5 Lb-In	Free Hanging (In-Line)	Thermoplastic	Tin	1	11	0.587 in	14.91 mm
AMPHENOL ANYTEK EO100102A000G	5 mm	0.197 in	Screw	M3	Plug for Unshrouded Header	-40 °C	115 °C	300 V	Phosphor Bronze	15.9 mm	0.626 in	10	Black	90 °	UL94 V-0	5 mm	6 mm	28 AWG	12 AWG	0.51 Nm	4.5 Lb-In	Free Hanging (In-Line)	Thermoplastic	Tin	1	10
AMPHENOL ANYTEK EO040102A000G	5 mm	0.197 in	Screw	M3	Plug for Unshrouded Header	-40 °C	115 °C	300 V	Phosphor Bronze	15.9 mm	0.626 in	4	Black	90 °	UL94 V-0	5 mm	6 mm	28 AWG	12 AWG	0.51 Nm	4.5 Lb-In	Free Hanging (In-Line)	Thermoplastic	Tin	1	4
AMPHENOL ANYTEK EO0301020000G	5 mm	0.197 in	Screw	M3	Plug for Unshrouded Header	-40 °C	115 °C	300 V	Phosphor Bronze			3	Black	90 °	UL94 V-0	5 mm	6 mm	28 AWG	12 AWG	0.51 Nm	4.5 Lb-In	Free Hanging (In-Line)	Thermoplastic	Tin	1		0.587 in	14.91 mm
AMPHENOL ANYTEK EO1001000000G	5 mm	0.197 in	Screw	M3	Plug for Unshrouded Header	-40 °C	115 °C	300 V	Phosphor Bronze			10	Black	90 °	UL94 V-0	5 mm	6 mm	28 AWG	12 AWG	0.51 Nm	4.5 Lb-In	Free Hanging (In-Line)	Thermoplastic	Tin	1	10	0.587 in	14.91 mm
AMPHENOL ANYTEK EO220102A000G	5 mm	0.197 in	Screw	M3	Plug for Unshrouded Header	-40 °C	115 °C	300 V	Phosphor Bronze	15.9 mm	0.626 in	22	Black	90 °	UL94 V-0	5 mm	6 mm	28 AWG	12 AWG	0.51 Nm	4.5 Lb-In	Free Hanging (In-Line)	Thermoplastic	Tin	1	22 positions
AMPHENOL ANYTEK EO0301000000G	5 mm	0.197 in	Screw	M3	Plug for Unshrouded Header	-40 °C	115 °C	300 V	Phosphor Bronze			3	Black	90 °	UL94 V-0	5 mm	6 mm	28 AWG	12 AWG	0.51 Nm	4.5 Lb-In	Free Hanging (In-Line)	Thermoplastic	Tin	1		0.587 in	14.91 mm
AMPHENOL ANYTEK EO080102A000G	5 mm	0.197 in	Screw	M3	Plug for Unshrouded Header	-40 °C	115 °C	300 V	Phosphor Bronze	15.9 mm	0.626 in	8	Black	90 °	UL94 V-0	5 mm	6 mm	28 AWG	12 AWG	0.51 Nm	4.5 Lb-In	Free Hanging (In-Line)	Thermoplastic	Tin	1	8
AMPHENOL ANYTEK EO0501000000G	5 mm	0.197 in	Screw	M3	Plug for Unshrouded Header	-40 °C	115 °C	300 V	Phosphor Bronze			5	Black	90 °	UL94 V-0	5 mm	6 mm	28 AWG	12 AWG	0.51 Nm	4.5 Lb-In	Free Hanging (In-Line)	Thermoplastic	Tin	1		0.587 in	14.91 mm
