AME60-12SMJZ

Active

aimtec

12V 90VAC~264VAC 5A 60W 86% DIP-6 AC-DC POWER MODULES ROHS

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

AME60-12SMJZ

Active

aimtec

12V 90VAC~264VAC 5A 60W 86% DIP-6 AC-DC POWER MODULES ROHS

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	AME60-12SMJZ

Applications	ITE (Commercial)
Approval Agency	CE, cURus
Current - Output (Max) [Max]	5 A
Efficiency	86 %
Features	Adjustable Output, Universal Input
Line Regulation	0.5 %
Load Regulation	0.5 %
Mounting Type	Through Hole
Number of Outputs	1
Package / Case	6-DIP Module
Power (Watts)	60 W
Type	Enclosed
Voltage - Input [Max]	264 VAC
Voltage - Input [Min]	90 VAC
Voltage - Output 1	12 V
Weight	0.683 lb
Weight	310 g

AME60 Series

Part	Number of Outputs	Mounting Type	Power (Watts)	Weight	Weight	Type	Current - Output (Max) [Max]	Load Regulation	Standard Number	Voltage - Input [Min]	Voltage - Input [Max]	Package / Case	Voltage - Output 1	Line Regulation	Efficiency	Applications	Approval Agency	Features	Operating Temperature [Min]	Operating Temperature [Max]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [x]	Current - Output 1	Voltage - Isolation
aimtec AME60-12S277VZ	1	Through Hole	60 W	300 g	0.661 lb	Enclosed	5 A	1 %	62368-1	85 VAC 100 V	305 VAC 430 VDC	6-DIP Module	12 V	0.5 %	86 %	ITE (Commercial)
aimtec AME60-12SMJZ	1	Through Hole	60 W	310 g	0.683 lb	Enclosed	5 A	0.5 %		90 VAC	264 VAC	6-DIP Module	12 V	0.5 %	86 %	ITE (Commercial)	CE cURus	Adjustable Output Universal Input
aimtec AME60-5SVZ	1	Through Hole	50 W	310 g	0.683 lb	Enclosed	10 A	1 %		85 VAC 100 V	264 VAC 370 VDC	6-DIP Module	5 V	0.5 %		ITE (Commercial)		Universal Input
aimtec AME60-15SVZ	1	Through Hole	60 W	310 g	0.683 lb	Enclosed	4 A	1 %				6-DIP Module	15 V	0.5 %	86 %	ITE (Commercial)		Universal Input
aimtec AME60-48SVZ	1	Through Hole	60 W	310 g	0.683 lb	Enclosed	1.25 A	1 %				6-DIP Module	48 V	0.5 %	86 %	ITE (Commercial)		Universal Input
aimtec AME60-24S277VZ	1	Through Hole	60 W	300 g	0.661 lb	Enclosed	2.5 A	1 %	62368-1	85 VAC 100 V	305 VAC 430 VDC	6-DIP Module	24 V	0.5 %	86 %	ITE (Commercial)
aimtec AME60-12SVZ-ST	1	Chassis Mount				Enclosed				85 VAC 100 V	264 VAC 370 VDC		12 V		86 %	ITE (Commercial)		Universal Input	-40 °C	70 °C	1.52 in	5.32 in	2.76 in	70 mm	38.5 mm	135 mm	5 A	4000 V
aimtec AME60-48SVZ-ST	1	Chassis Mount				Enclosed			62368-1				48 V		86 %	ITE (Commercial)		Adjustable Output Universal Input			1.52 in	5.23 "	2.76 in	70 mm	38.5 mm	135 mm	1.25 A	4000 V
aimtec AME60-5S277VZ	1	Through Hole	50 W	300 g	0.661 lb	Enclosed	10 A	1 %	62368-1	85 VAC 100 V	305 VAC 430 VDC	6-DIP Module	5 V	0.5 %		ITE (Commercial)
aimtec AME60-12SVZ	1	Through Hole	60 W	310 g	0.683 lb	Enclosed	5 A	1 %				6-DIP Module	12 V	0.5 %	86 %	ITE (Commercial)		Universal Input

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

LCSC	Piece	1	$ 145.09
		200	$ 57.89
		500	$ 55.96
		1000	$ 55.00

Description

General part information

AME60 Series

Enclosed AC DC Converters 1 Output 12V 5A 90 ~ 264 VAC Input
