OSA-SS-224DM3,000

Obsolete

TE Connectivity Potter & Brumfield Relays

RELAY GEN PURPOSE DPST 3A 24V

Search across all available documentation for this part.

Obsolete

TE Connectivity Potter & Brumfield Relays

RELAY GEN PURPOSE DPST 3A 24V

Technical Specifications

Parameters and characteristics for this part

Part	Coil Voltage	Contact Material	Mounting Type	Coil Current	Contact Rating (Current)	Contact Form	Approval Agency	Termination Style	Operate Time	Must Release Voltage	Seal Rating	Release Time	Switching Voltage	Load - Max Switching	Must Operate Voltage	Coil Type	Relay Type	Operating Temperature [Min]	Operating Temperature [Max]	Coil Resistance
TE Connectivity Potter & Brumfield Relays OSA-SS-224DM3,000	24 VDC	Silver Alloy	Through Hole	22.5 mA	3 A	DPST-NO (2 Form A)	CQC CSA TUV UR	PC Pin	20 ms	1.2 VDC	Sealed - Flux Protection	10 ms	30 VDC 240 VAC	90 W 720 VA	18 VDC	Non Latching	General Purpose	-30 ░C	60 °C
TE Connectivity Potter & Brumfield Relays OSA-SS-212DM5,000	12 VDC	Silver Tin Oxide (AgSnO)	Through Hole	45 mA	5 A	DPST-NO (2 Form A)	CQC CSA TUV UR	PC Pin	20 ms	0.6 VDC	Sealed - Flux Protection	10 ms	30 VDC 240 VAC	150 W 1200 VA	9 VDC	Non Latching	General Purpose	-30 ░C	60 °C	270 Ohms
TE Connectivity Potter & Brumfield Relays OSA-SS-212DM3M,000	12 VDC	Silver Alloy	Through Hole	44.4 mA	3 A	DPST-NO (2 Form A)	CQC CSA TUV UR	PC Pin	20 ms	0.6 VDC	Sealed - Fully	10 ms	30 VDC 240 VAC	90 W 720 VA	9 VDC	Non Latching	General Purpose	-30 ░C	60 °C	270 Ohms
TE Connectivity Potter & Brumfield Relays OSA-SS-212DM3,000	12 VDC	Silver Alloy	Through Hole	45 mA	3 A	DPST-NO (2 Form A)	CQC CSA TUV UR	PC Pin	20 ms	0.6 VDC	Sealed - Flux Protection	10 ms	30 VDC 240 VAC	90 W 720 VA	9 VDC	Non Latching	General Purpose	-30 ░C	60 °C	270 Ohms

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

General Purpose Relay DPST-NO (2 Form A) 24VDC Coil Through Hole
