AM10CW-2415D-NZ

Active

aimtec

DC DC CONVERTER +/-15V 10W

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

AM10CW-2415D-NZ

Active

aimtec

DC DC CONVERTER +/-15V 10W

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics commom to parts in this series

Specification	AM10CW-2415D-NZ	AM10C Series

Applications	ITE (Commercial)	ITE (Commercial)
Approval Agency	CE, cURus, UL	CE, cURus, UL
Current - Output (Max)	330 mA	1 - 550 mA
Current - Output (Max)	330 mA	1 - 550 mA
Current - Output (Max)	-	1.11 - 830 mA
Current - Output (Max)	-	410 mA
Efficiency	87 %	79 - 88 %
Features	Remote On/Off	Remote On/Off
Mounting Type	Through Hole	Through Hole
Number of Outputs	2	1 - 2
Operating Temperature [Max]	85 °C	85 °C
Operating Temperature [Min]	-40 °C	-40 °C
Package / Case	-	7-DIP Module, 6-DIP Module
Package / Case	-	5 Leads
Power (Watts)	10 W	4.95 - 10 W
Size / Dimension	-	0.4 "
Size / Dimension	-	25.4 mm
Size / Dimension	-	1 in
Size / Dimension [x]	25.4 mm	25.4 mm
Size / Dimension [x]	25.4 mm	25.4 mm
Size / Dimension [y]	25.4 mm	25.4 mm
Size / Dimension [y]	25.4 mm	25.4 mm
Size / Dimension [z]	0.46 in	0.46 - 10.2 in
Size / Dimension [z]	11.7 mm	11.7 mm
Type	Isolated Module	Isolated Module
Voltage - Input (Max) [Max]	36 V	36 - 75 V
Voltage - Input (Min) [Min]	9 V	9 - 18 V
Voltage - Isolation	1.5 kV	1.5 kV
Voltage - Output 1	-	3.3 - 24 V
Voltage - Output 1 [Max]	15 V	5 - 24 V
Voltage - Output 1 [Min]	-15 V	-24 - 5 V
Voltage - Output 2	-15 V	-24 - 24 V

AM10C Series

DC DC CONVERTER 12V 10W

Part	Approval Agency	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [x]	Mounting Type	Voltage - Isolation	Applications	Features	Power (Watts)	Current - Output (Max) [Max]	Operating Temperature [Max]	Operating Temperature [Min]	Number of Outputs	Voltage - Input (Max) [Max]	Efficiency	Type	Voltage - Input (Min) [Min]	Voltage - Output 1	Voltage - Output 1 [Min]	Voltage - Output 1 [Max]	Voltage - Output 2	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [x]	Current - Output (Max)	Current - Output (Max)
aimtec AM10CW-4812S-NZ	CE, cURus, UL	25.4 mm	0.46 in	25.4 mm	11.7 mm	25.4 mm	25.4 mm	Through Hole	1.5 kV	ITE (Commercial)	Remote On/Off	10 W	830 mA	85 °C	-40 °C	1	75 V	87 %	Isolated Module	18 V	12 V
aimtec AM10CW-4803S-NZ	CE, cURus, UL	25.4 mm	0.46 in	25.4 mm	11.7 mm	25.4 mm	25.4 mm	Through Hole	1.5 kV	ITE (Commercial)	Remote On/Off	10 W	2.4 A	85 °C	-40 °C	1	75 V	79 %	Isolated Module	18 V	3.3 V
aimtec AM10CW-2409S-NZ	CE, cURus, UL	25.4 mm	0.46 in	25.4 mm	11.7 mm	25.4 mm	25.4 mm	Through Hole	1.5 kV	ITE (Commercial)	Remote On/Off	10 W	1.11 A	85 °C	-40 °C	1	36 V	86 %	Isolated Module	9 V	9 V
aimtec AM10CW-2405S-NZ	CE, cURus, UL	25.4 mm	0.46 in	25.4 mm	11.7 mm	25.4 mm	25.4 mm	Through Hole	1.5 kV	ITE (Commercial)	Remote On/Off	10 W	2 A	85 °C	-40 °C	1	36 V	83 %	Isolated Module	9 V	5 V
aimtec AM10CW-2412S-NZ	CE, cURus, UL	25.4 mm	0.46 in	25.4 mm	11.7 mm	25.4 mm	25.4 mm	Through Hole	1.5 kV	ITE (Commercial)	Remote On/Off	10 W	830 mA	85 °C	-40 °C	1	36 V	87 %	Isolated Module	9 V	12 V
aimtec AM10CW-2424D-NZ	CE, cURus, UL	25.4 mm	0.46 in	25.4 mm	11.7 mm	25.4 mm	25.4 mm	Through Hole	1.5 kV	ITE (Commercial)	Remote On/Off	10 W		85 °C	-40 °C	2	36 V	87 %	Isolated Module	9 V		-24 V	24 V	-24 V
aimtec AM10C-2405S-NZ		25.4 mm	10.2 mm			25.4 mm		Through Hole	1.5 kV	ITE (Commercial)	Remote On/Off	10 W	2 A	85 °C	-40 °C	1	36 V	83 %	Isolated Module	18 V	5 V				0.4 "	25.4 mm	1 in
aimtec AM10CW-4824S-NZ	CE, cURus, UL	25.4 mm	0.46 in	25.4 mm	11.7 mm	25.4 mm	25.4 mm	Through Hole	1.5 kV	ITE (Commercial)	Remote On/Off	10 W	410 mA	85 °C	-40 °C	1	75 V	88 %	Isolated Module	18 V	24 V
aimtec AM10CW-2415S-NZ	CE, cURus, UL	25.4 mm	0.46 in	25.4 mm	11.7 mm	25.4 mm	25.4 mm	Through Hole	1.5 kV	ITE (Commercial)	Remote On/Off	10 W	660 mA	85 °C	-40 °C	1	36 V	87 %	Isolated Module	9 V	15 V
aimtec AM10CW-2415D-NZ	CE, cURus, UL	25.4 mm	0.46 in	25.4 mm	11.7 mm	25.4 mm	25.4 mm	Through Hole	1.5 kV	ITE (Commercial)	Remote On/Off	10 W		85 °C	-40 °C	2	36 V	87 %	Isolated Module	9 V		-15 V	15 V	-15 V				330 mA	330 mA

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Description

General part information

AM10C Series

Isolated Module DC DC Converter 2 Output -15 ~ 15V -15V 330mA, 330mA 9V - 36V Input
