53894-1
ActiveTE Connectivity AMP Connectors
CONN HOUSING RCP 1 POS CRIMP ST CABLE MOUNT WHITE LOOSE
53894-1
ActiveTE Connectivity AMP Connectors
CONN HOUSING RCP 1 POS CRIMP ST CABLE MOUNT WHITE LOOSE
Description
General part information
53894 Series
1 Position, Plug / Receptacle, Housing, Crimp & Solder, Wire-to-Wire, UL 94V-2, 1 Row, 600 VAC, Wire & Cable, Power, Panel Mount
Technical Specifications
Parameters and characteristics for this part
| Specification | 53894-1 |
|---|---|
| Color | White |
| Connector Type | Receptacle, Self Mating |
| Contact Termination | Crimp |
| Contact Type | Non-Gendered |
| Fastening Type | Locking Ramp |
| Insulation Material | Polycarbonate (PC) |
| Mounting Type | Free Hanging (In-Line) |
| Note | Contacts Not Included |
| Number of Positions | 1 |
| Number of Rows | 1 |
| Operating Temperature (Max) | 75 °C |
| Operating Temperature (Min) | -40 °C |
