QS54FCT245CTS0
ActiveQuality Semiconductor
BUS TRANSCEIVER, FCT SERIES, 8
Deep-Dive with AI
Search across all available documentation for this part.
QS54FCT245CTS0
ActiveQuality Semiconductor
BUS TRANSCEIVER, FCT SERIES, 8
Deep-Dive with AI
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | QS54FCT245CTS0 | 54FCT245 Series |
|---|---|---|
| Current - Output High, Low [custom] | 12 mA | 12 mA |
| Current - Output High, Low [custom] | 48 mA | 48 mA |
| Mounting Type | Surface Mount | Through Hole, Surface Mount |
| Number of Bits per Element | 8 | 4 - 8 |
| Number of Elements | 1 | 1 - 2 |
| Operating Temperature [Max] | 125 °C | 125 °C |
| Operating Temperature [Min] | -55 °C | -55 °C |
| Output Type | 3-State | 3-State |
| Package / Case | - | 20-CDIP |
| Supplier Device Package | - | 20-CDIP |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 485 | $ 0.62 | |
54FCT245 Series
IC BUFFER NON-INVERT 5V
| Part | Package / Case | Operating Temperature [Min] | Operating Temperature [Max] | Number of Bits per Element | Mounting Type | Supplier Device Package | Current - Output High, Low [custom] | Current - Output High, Low [custom] | Number of Elements | Output Type |
|---|---|---|---|---|---|---|---|---|---|---|
Quality Semiconductor QS54FCT245ATDB | 20-CDIP | -55 °C | 125 °C | 4 | Through Hole | 20-CDIP | 12 mA | 48 mA | 2 | 3-State |
Quality Semiconductor QS54FCT245CTS0 | -55 °C | 125 °C | 8 | Surface Mount | 12 mA | 48 mA | 1 | 3-State |
Description
General part information
54FCT245 Series
Transceiver, Non-Inverting 1 Element 8 Bit per Element 3-State Output
Documents
Technical documentation and resources
No documents available
