9-1437356-2
ActiveTE Connectivity Raychem Cable Protection
CBL RIBN 20COND 0.05 BLUE 328.1'
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | 9-1437356-2 |
|---|---|
| Cable Type | Flat Cable |
| Conductor Material | Copper, Tinned |
| Conductor Strand [custom] | 7 |
| Conductor Strand [custom] | 36 AWG |
| Current Rating (Amps) | 2 A |
| First Conductor Mark | Blue |
| Insulation Resistance | 10 GOhm |
| Jacket (Insulation) Material | Poly-Vinyl Chloride (PVC) |
| Jacket Color | Blue |
| Length | 328.1 ft |
| Length | 100 m |
| Number of Conductors | 20 |
| Operating Temperature [Max] | 105 ░C |
| Operating Temperature [Min] | -20 C |
| Pitch [x] | 0.05 in |
| Pitch [x] | 1.27 mm |
| Ratings | UL Style 2651 |
| Ribbon Thickness | 0.91 mm |
| Ribbon Thickness | 0.036 " |
| Ribbon Width | 1 in |
| Ribbon Width | 25.4 mm |
| Shielding | Unshielded |
| Voltage | 300 V |
| Wire Gauge | 28 AWG |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 117.51 | |
| 4 | $ 113.15 | |||
| 13 | $ 110.98 | |||
| 200 | $ 108.80 | |||
Description
General part information
1437356 Series
Flat Ribbon Cable Blue 20 Conductors 0.050" (1.27mm) Flat Cable 328.1' (100.00m)
