ECA-1CHG471B

Active

Panasonic Industrial Automation Sales

CAP ALUM 470UF 20% 16V RADIAL TH

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

ECA-1CHG471B

Active

Panasonic Industrial Automation Sales

CAP ALUM 470UF 20% 16V RADIAL TH

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	ECA-1CHG471B

Applications	Automotive
Capacitance	470 µF
Height - Seated (Max) [Max]	0.492 in
Height - Seated (Max) [Max]	12.5 mm
Lead Spacing	5 mm
Lead Spacing	0.197 in
Lifetime @ Temp.	1000 Hrs
Mounting Type	Through Hole
Operating Temperature [Max]	105 ░C
Operating Temperature [Min]	-55 °C
Package / Case	Radial, Can
Polarization	Polar
Ratings	AEC-Q200
Ripple Current @ High Frequency	418.5 mA
Ripple Current @ Low Frequency	310 mA
Size / Dimension [diameter]	0.315 "
Size / Dimension [diameter]	8 mm
Tolerance	20 %
Voltage - Rated	16 V

ECA-1CH Series

Part	Package / Case	Ratings	Ripple Current @ High Frequency	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Lead Spacing	Lead Spacing	Capacitance	Ripple Current @ Low Frequency	Mounting Type	Polarization	Operating Temperature [Max]	Operating Temperature [Min]	Voltage - Rated	Size / Dimension [diameter]	Size / Dimension [diameter]	Lifetime @ Temp.	Applications	Tolerance	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]
Panasonic Industrial Automation Sales ECA-1CHG332B	Radial Can	AEC-Q200	1.346 A	1.063 in	27 mm	5 mm	0.197 in	3.3 mF	1.17 A	Through Hole	Polar	105 ░C	-55 °C	16 V	0.492 in	12.5 mm	2000 Hrs	Automotive	20 %
Panasonic Industrial Automation Sales ECA-1CHG682	Radial Can		2.047 A			7.5 mm	0.295 in	6800 µF	1.78 A	Through Hole	Polar	105 ░C	-55 °C	16 V	0.63 in	16 mm	2000 Hrs	General Purpose	20 %
Panasonic Industrial Automation Sales ECA-1CHG471B	Radial Can	AEC-Q200	418.5 mA			5 mm	0.197 in	470 µF	310 mA	Through Hole	Polar	105 ░C	-55 °C	16 V	0.315 "	8 mm	1000 Hrs	Automotive	20 %	0.492 in	12.5 mm
Panasonic Industrial Automation Sales ECA-1CHG331B	Radial Can		390 mA			5 mm	0.197 in	330 µF	260 mA	Through Hole	Polar	105 ░C	-55 °C	16 V	0.315 "	8 mm	1000 Hrs	General Purpose	20 %	0.492 in	12.5 mm
Panasonic Industrial Automation Sales ECA-1CHG101	Radial Can		165 mA	0.472 "	12 mm	2 mm	0.079 in	100 µF	110 mA	Through Hole	Polar	105 ░C	-55 °C	16 V	0.197 "	5 mm	1000 Hrs	General Purpose	20 %
Panasonic Industrial Automation Sales ECA-1CHG100	Radial Can	AEC-Q200						10 µF		Through Hole	Polar	105 ░C	-55 °C	16 V				Automotive	20 %
Panasonic Industrial Automation Sales ECA-1CHG332	Radial Can		1.346 A	1.063 in	27 mm	5 mm	0.197 in	3.3 mF	1.17 A	Through Hole	Polar	105 ░C	-55 °C	16 V	0.492 in	12.5 mm	2000 Hrs	General Purpose	20 %
Panasonic Industrial Automation Sales ECA-1CHG470I	Radial Can		115.5 mA	0.472 "	12 mm	2.5 mm	0.098 in	47 µF	77 mA	Through Hole	Polar	105 ░C	-55 °C	16 V	0.197 "	5 mm	1000 Hrs	General Purpose	20 %
Panasonic Industrial Automation Sales ECA-1CHG100B	Radial Can							10 µF		Through Hole	Polar	105 ░C	-55 °C	16 V				General Purpose	20 %
Panasonic Industrial Automation Sales ECA-1CHG222B	Radial Can		1.058 A	0.866 in	22 mm	5 mm	0.197 in	2200 µF	920 mA	Through Hole	Polar	105 ░C	-55 °C	16 V	0.492 in	12.5 mm	2000 Hrs	General Purpose	20 %

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Cut Tape (CT)	1	$ 0.52
		10	$ 0.32
		50	$ 0.24
		100	$ 0.21
		500	$ 0.17
	Tape & Box (TB)	1000	$ 0.14
		2000	$ 0.13
		3000	$ 0.13
		5000	$ 0.12
		7000	$ 0.12
		10000	$ 0.11
		25000	$ 0.10
		50000	$ 0.10
		100000	$ 0.10

Description

General part information

ECA-1CH Series

470 µF 16 V Aluminum Electrolytic Capacitors Radial, Can 1000 Hrs @ 105°C
