BQ24250YFFR
Active1-CELL, 2-A, I<SUP>2</SUP>C CONTROLLED BUCK BATTERY CHARGER WITH 1UA IN SYSOFF MODE AND TS DISABLE FUNCTION 30-DSBGA -40 TO 85
Deep-Dive with AI
Search across all available documentation for this part.
BQ24250YFFR
Active1-CELL, 2-A, I<SUP>2</SUP>C CONTROLLED BUCK BATTERY CHARGER WITH 1UA IN SYSOFF MODE AND TS DISABLE FUNCTION 30-DSBGA -40 TO 85
Deep-Dive with AI
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | BQ24250YFFR | BQ24250 Series |
|---|---|---|
| Battery Chemistry | Lithium Ion | Lithium Ion |
| Battery Pack Voltage | 4.2 V | 4.2 V |
| Charge Current - Max [Max] | 2 A | 2 A |
| Current - Charging | Constant - Programmable | Constant - Programmable |
| Fault Protection | Over Current, Over Voltage, Over Temperature | Over Voltage, Over Temperature, Over Current |
| Function | - | Battery Charger |
| Interface | I2C | I2C |
| Mounting Type | Surface Mount | Surface Mount |
| Number of Cells | 1 | 1 |
| Operating Temperature [Max] | 85 °C | 85 °C |
| Operating Temperature [Min] | -40 °C | -40 °C |
| Package / Case | 30-UFBGA, DSBGA | 30-UFBGA, DSBGA |
| Programmable Features | Current | Current |
| Supplied Contents | - | Board(s) |
| Supplier Device Package | 30-DSBGA | 30-DSBGA |
| Type | - | Power Management |
| Utilized IC / Part | - | BQ24250 |
| Voltage - Supply (Max) [Max] | 10.5 V | 10.5 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| DigiKey | N/A | 1 | $ 4.60 | |
| 10 | $ 3.49 | |||
| 25 | $ 3.22 | |||
| 100 | $ 2.91 | |||
| 111 | $ 2.69 | |||
| 250 | $ 2.77 | |||
| 500 | $ 2.68 | |||
| 1000 | $ 2.61 | |||
| 3000 | $ 2.33 | |||
| Digikey | Cut Tape (CT) | 1 | $ 5.03 | |
| 10 | $ 4.52 | |||
| 25 | $ 4.27 | |||
| 100 | $ 3.70 | |||
| 250 | $ 3.51 | |||
| 500 | $ 3.15 | |||
| 1000 | $ 2.66 | |||
| Digi-Reel® | 1 | $ 5.03 | ||
| 10 | $ 4.52 | |||
| 25 | $ 4.27 | |||
| 100 | $ 3.70 | |||
| 250 | $ 3.51 | |||
| 500 | $ 3.15 | |||
| 1000 | $ 2.66 | |||
| Tape & Reel (TR) | 3000 | $ 2.35 | ||
| LCSC | N/A | 1 | $ 2.73 | |
| 10 | $ 2.44 | |||
| 30 | $ 2.25 | |||
| 100 | $ 2.07 | |||
| Mouser Electronics | N/A | 1 | $ 3.54 | |
| 10 | $ 2.88 | |||
| 100 | $ 2.72 | |||
| 250 | $ 2.64 | |||
| 500 | $ 2.57 | |||
| 1000 | $ 2.52 | |||
| 3000 | $ 2.35 | |||
| Rochester Electronics | N/A | 1 | $ 2.61 | |
| 25 | $ 2.56 | |||
| 100 | $ 2.45 | |||
| 500 | $ 2.35 | |||
| 1000 | $ 2.22 | |||
| Texas Instruments | LARGE T&R | 1 | $ 3.80 | |
| 100 | $ 3.33 | |||
| 250 | $ 2.33 | |||
| 1000 | $ 1.88 | |||
| Win Source Electronics | N/A | 14 | $ 3.74 | |
| 33 | $ 3.07 | |||
| 51 | $ 2.97 | |||
| 70 | $ 2.88 | |||
| 90 | $ 2.78 | |||
| 121 | $ 2.49 | |||
BQ24250 Series
1-cell, 2-A, I2C controlled buck battery charger with 1uA in SYSOFF mode and TS disable function
| Part | Current - Charging | Operating Temperature [Max] | Operating Temperature [Min] | Battery Pack Voltage | Battery Chemistry | Mounting Type | Supplier Device Package | Programmable Features | Voltage - Supply (Max) [Max] | Interface | Number of Cells | Package / Case | Fault Protection | Charge Current - Max [Max] | Utilized IC / Part | Type | Function | Supplied Contents |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Texas Instruments BQ24250CYFFT | Constant - Programmable | 85 °C | -40 °C | 4.2 V | Lithium Ion | Surface Mount | 30-DSBGA | Current | 10.5 V | I2C | 1 | 30-UFBGA, DSBGA | Over Temperature, Over Voltage | 2 A | ||||
Texas Instruments BQ24250YFFT | Constant - Programmable | 85 °C | -40 °C | 4.2 V | Lithium Ion | Surface Mount | 30-DSBGA | Current | 10.5 V | I2C | 1 | 30-UFBGA, DSBGA | Over Current, Over Temperature, Over Voltage | 2 A | ||||
Texas Instruments BQ24250YFFR | Constant - Programmable | 85 °C | -40 °C | 4.2 V | Lithium Ion | Surface Mount | 30-DSBGA | Current | 10.5 V | I2C | 1 | 30-UFBGA, DSBGA | Over Current, Over Temperature, Over Voltage | 2 A | ||||
Texas Instruments BQ24250EVM-150 | BQ24250 | Power Management | Battery Charger | Board(s) |
Description
General part information
BQ24250 Series
The bq24250, bq24251, and bq24253 are highly integrated single-cell Li-Ion battery chargers and system power-path management devices targeted for space-limited, portable applications with high-capacity batteries. The single-cell charger has a single input that operates from either a USB port or an AC wall adapter for a versatile solution.
The power-path management feature allows the bq24250, bq24251, and bq24253 to power the system from a high-efficiency DC-DC converter while simultaneously and independently charging the battery. The charger monitors the battery current at all times and reduces the charge current when the system load requires current above the input current limit. This reduced charge current allows for proper charge termination and enables the system to run with a defective or absent battery pack. Additionally, this reduced charge current enables instant system turnon even with a totally discharged battery or no battery. The architecture of the power-path management also permits the battery to supplement the system current requirements when the adapter cannot deliver the peak system currents. This supplementation of current requirements enables the use of a smaller adapter.
The battery is charged in four phases: trickle charge, precharge, constant current, and constant voltage. In all charge phases, an internal control loop monitors the IC junction temperature and reduces the charge current if the internal temperature threshold is exceeded. Additionally, a voltage-based, JEITA compatible battery pack thermistor monitoring input (TS) that monitors battery temperature for safe charging is included.
