| 3 Wire Leads | Tubeaxial | 0.2 A | Speed Sensor (Tach), Thermal Overload Protector (TOP) | 80 mm | 80 mm | Polybutylene Terephthalate (PBT) | 37 dB | 24 VDC | 49.8 Pa | 0.2 in H2O | CE, cUL, TUV, UL | Ball | 1.37 m³/min | 49 CFM | 4000 RPM | 20.8 mm |
| 3 Wire Leads | Tubeaxial | 110 mA | Speed Sensor (Tach), Thermal Overload Protector (TOP) | 80 mm | 80 mm | Polybutylene Terephthalate (PBT) | 25 dB(A) | 12 VDC | 24.9 Pa | 0.1 in H2O | CE, cUL, TUV, UL | Ball | 0.868 mł/min | 31 CFM | 2500 RPM | 20.8 mm |
| 4 Wire Leads | Tubeaxial | 0.2 A | Alarm Sensor, Speed Sensor (Tach), Thermal Overload Protector (TOP) | 80 mm | 80 mm | Polybutylene Terephthalate (PBT) | 37 dB | 24 VDC | 49.8 Pa | 0.2 in H2O | CE, cUL, TUV, UL | Ball | 1.37 m³/min | 49 CFM | 4000 RPM | 20.8 mm |
| 2 Wire Leads | Tubeaxial | 0.2 A | Thermal Overload Protector (TOP) | 80 mm | 80 mm | Polybutylene Terephthalate (PBT) | 22 dB(A) | 5 V | 14.9 Pa | 0.06 in H2O | CE, cUL, TUV, UL | Ball | 0.672 mł/min | 24 CFM | 2000 RPM | 20.8 mm |
| 3 Wire Leads | Tubeaxial | 70 mA | Speed Sensor (Tach), Thermal Overload Protector (TOP) | 80 mm | 80 mm | Polybutylene Terephthalate (PBT) | 22 dB(A) | 12 VDC | 14.9 Pa | 0.06 in H2O | CE, cUL, TUV, UL | Ball | 0.672 mł/min | 24 CFM | 2000 RPM | 20.8 mm |
| 2 Wire Leads | Tubeaxial | 400 mA | Thermal Overload Protector (TOP) | 80 mm | 80 mm | Polybutylene Terephthalate (PBT) | 29 dB(A) | 5 V | 32.4 Pa | 0.13 in H2O | CE, cUL, TUV, UL | Ball | 1.06 mł/min | 38 CFM | 3000 RPM | 20.8 mm |
| 2 Wire Leads | Tubeaxial | 75 mA | Thermal Overload Protector (TOP) | 80 mm | 80 mm | Polybutylene Terephthalate (PBT) | 25 dB(A) | 24 VDC | 24.9 Pa | 0.1 in H2O | CE, cUL, TUV, UL | Ball | | | 2500 RPM | 20.8 mm |
| 2 Wire Leads | Tubeaxial | | Thermal Overload Protector (TOP) | 80 mm | 80 mm | Polybutylene Terephthalate (PBT) | 29 dB(A) | 12 VDC | 32.4 Pa | 0.13 in H2O | CE, cUL, TUV, UL | Ball | 1.06 mł/min | 38 CFM | 3000 RPM | 20.8 mm |
| 4 Wire Leads | Tubeaxial | 0.23 A | PWM Control, Speed Sensor (Tach), Thermal Overload Protector (TOP) | 80 mm | 80 mm | Polybutylene Terephthalate (PBT) | 33 dB(A) | 12 VDC | 42.3 Pa | 0.17 in H2O | CE, cUL, TUV, UL | Ball | 1.2 m³/min | 43 CFM | 3500 RPM | 20.8 mm |
| 2 Wire Leads | Tubeaxial | 70 mA | Thermal Overload Protector (TOP) | 80 mm | 80 mm | Polybutylene Terephthalate (PBT) | 22 dB(A) | 12 VDC | 14.9 Pa | 0.06 in H2O | CE, cUL, TUV, UL | Ball | 0.672 mł/min | 24 CFM | 2000 RPM | 20.8 mm |
