IXD5120C182NR-G

Active

Zilog

IC SUPERVISOR 1 CHANNEL SSOT24

Search across all available documentation for this part.

Active

Zilog

IC SUPERVISOR 1 CHANNEL SSOT24

Technical Specifications

Parameters and characteristics commom to parts in this series

Specification	IXD5120C182NR-G	IXD5120 Series

Mounting Type	Surface Mount	Surface Mount
Number of Voltages Monitored	1	1
Operating Temperature [Max]	85 °C	85 °C
Operating Temperature [Min]	-40 °C	-40 °C
Output	Totem Pole, Push-Pull	Totem Pole, Push-Pull, Open Drain or Open Collector
Package / Case	SC-82	SC-82
Reset	Active Low	Active Low
Supplier Device Package	SSOT-24	SSOT-24
Type	Simple Reset/Power-On Reset	Simple Reset/Power-On Reset
Voltage - Threshold	1.8 V	1.5 - 3 V

IC SUPERVISOR 1 CHANNEL SSOT24

Part	Type	Reset	Package / Case	Mounting Type	Operating Temperature [Max]	Operating Temperature [Min]	Number of Voltages Monitored	Supplier Device Package	Voltage - Threshold	Output
Zilog IXD5120C182NR-G	Simple Reset/Power-On Reset	Active Low	SC-82	Surface Mount	85 °C	-40 °C	1	SSOT-24	1.8 V	Push-Pull, Totem Pole
Zilog IXD5120N302NR-G	Simple Reset/Power-On Reset	Active Low	SC-82	Surface Mount	85 °C	-40 °C	1	SSOT-24	3 V	Open Drain or Open Collector
Zilog IXD5120N182NR-G	Simple Reset/Power-On Reset	Active Low	SC-82	Surface Mount	85 °C	-40 °C	1	SSOT-24	1.8 V	Open Drain or Open Collector
Zilog IXD5120N152NR-G	Simple Reset/Power-On Reset	Active Low	SC-82	Surface Mount	85 °C	-40 °C	1	SSOT-24	1.5 V	Open Drain or Open Collector
Zilog IXD5120C252NR-G	Simple Reset/Power-On Reset	Active Low	SC-82	Surface Mount	85 °C	-40 °C	1	SSOT-24	2.5 V	Push-Pull, Totem Pole
Zilog IXD5120C152NR-G	Simple Reset/Power-On Reset	Active Low	SC-82	Surface Mount	85 °C	-40 °C	1	SSOT-24	1.5 V	Push-Pull, Totem Pole
Zilog IXD5120C302NR-G	Simple Reset/Power-On Reset	Active Low	SC-82	Surface Mount	85 °C	-40 °C	1	SSOT-24	3 V	Push-Pull, Totem Pole

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Tape & Reel (TR)	42000	$ 0.17

General part information

Supervisor Push-Pull, Totem Pole 1 Channel SSOT-24
