CHV2512-FX-2203ELF
ActiveBourns Inc.
RES SMD 220K OHM 1% 1W 2512
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
CHV2512-FX-2203ELF
ActiveBourns Inc.
RES SMD 220K OHM 1% 1W 2512
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | CHV2512-FX-2203ELF |
|---|---|
| Composition | Thick Film |
| Features | High Voltage |
| Height - Seated (Max) [Max] [z] | 0.03 in |
| Height - Seated (Max) [Max] [z] | 0.75 mm |
| Number of Terminations | 2 |
| Operating Temperature [Max] | 155 °C |
| Operating Temperature [Min] | -55 °C |
| Package / Case | 6432 Metric |
| Package / Case | 2512 |
| Power (Watts) | 1 W |
| Resistance | 220 kOhms |
| Supplier Device Package | 2512 |
| Temperature Coefficient | 100 ppm/°C |
| Tolerance | 1 % |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Cut Tape (CT) | 1 | $ 0.73 | |
| 10 | $ 0.41 | |||
| 50 | $ 0.29 | |||
| 100 | $ 0.26 | |||
| 500 | $ 0.20 | |||
| 1000 | $ 0.18 | |||
| Digi-Reel® | 1 | $ 0.73 | ||
| 10 | $ 0.41 | |||
| 50 | $ 0.29 | |||
| 100 | $ 0.26 | |||
| 500 | $ 0.20 | |||
| 1000 | $ 0.18 | |||
| Tape & Reel (TR) | 4000 | $ 0.17 | ||
| 8000 | $ 0.15 | |||
| 12000 | $ 0.14 | |||
| 20000 | $ 0.13 | |||
| 28000 | $ 0.13 | |||
Description
General part information
CHV2512 Series
220 kOhms ±1% 1W Chip Resistor 2512 (6432 Metric) High Voltage Thick Film
