Specification	PSA05A-050QL6W

Applications	ITE (Commercial)
Approval Agency	CE, CB, cULus
Current - Output (Max)	1 A
Efficiency	Level VI
Form	Wall Mount (Class II)
Input Connector	NEMA 1-15P
Input Type	Fixed Blade
No Load Power Consumption (Max)	30 mW
Operating Temperature (Max)	40 °C
Operating Temperature (Min)	0 °C
Output Connector	USB A Receptacle
Power (Watts)	5 W
Region Utilized	North America
Size / Dimension Height	1.65 in
Size / Dimension Length	0.83 in
Size / Dimension Width	1.69 in
Voltage - Input (AC) Maximum	264 V
Voltage - Input (AC) Minimum	90 V
Voltage - Output	5 VDC
Weight	2.82 oz

PSA05A Series

Wall Mount AC Adapters 5W 5V 1A US USB Adapter Black

Part	Power (Watts)	Applications	Voltage - Output	Operating Temperature (Max)	Operating Temperature (Min)	No Load Power Consumption (Max)	Voltage - Input (AC) Minimum	Voltage - Input (AC) Maximum	Form	Region Utilized	Approval Agency	Efficiency	Input Type	Current - Output (Max)	Input Connector	Weight	Size / Dimension Width	Size / Dimension Length	Size / Dimension Height	Output Connector	Standard Number
Phihong USA PSA05A-050QL6W	5 W	ITE (Commercial)	5 VDC	40 °C	0 °C	30 mW	90 V	264 V	Wall Mount (Class II)	North America	CB CE cULus	Level VI	Fixed Blade	1 A	NEMA 1-15P	2.82 oz	1.69 in	0.83 in	1.65 in	USB A Receptacle
Phihong USA PSA05A-050QL6-H	5 W	ITE (Commercial)	5 VDC	40 °C	0 °C	30 mW	90 V	264 V	Wall Mount (Class II)	North America	BSMI cULus PSE	Level VI	Fixed Blade	1 A	NEMA 1-15P	2.82 oz	1.69 in	0.83 in	1.65 in	USB A Receptacle	55022 60950-1 62368-1 CNS13438 CNS14336-1 CNS15663
