BQ24232EVM
ActiveTexas Instruments
EVALUATION MODULE FOR BQ24232
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
BQ24232EVM
ActiveTexas Instruments
EVALUATION MODULE FOR BQ24232
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | BQ24232EVM | BQ24232 Series |
|---|---|---|
| Battery Chemistry | - | Lithium Ion |
| Battery Pack Voltage | - | 4.2 - 4.35 V |
| Charge Current - Max | - | 500 mA |
| Current - Charging | - | Constant - Programmable |
| Embedded | False | False |
| Fault Protection | - | Reverse Current, Over Voltage, Over Temperature, Short Circuit |
| Function | Battery Charger | Battery Charger |
| Interface | - | USB |
| Mounting Type | - | Surface Mount |
| Number of Cells | - | 1 |
| Operating Temperature | - | -40 - -5 °C |
| Operating Temperature | - | 125 °C |
| Package / Case | - | 16-VFQFN Exposed Pad |
| Primary Attributes | Li-Ion / Li-Pol (1 Cell) | Li-Ion / Li-Pol (1 Cell) |
| Programmable Features | - | Current, Timer |
| Secondary Attributes | Charge Timer | Charge Timer, On-Board LEDs |
| Supplied Contents | Board(s) | Board(s) |
| Supplier Device Package | - | 16-VQFN (3x3) |
| Type | Power Management | Power Management |
| Utilized IC / Part | BQ24232 | BQ24232, BQ24232H |
| Voltage - Supply (Max) | - | 10.2 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 58.80 | |
BQ24232 Series
USB FRIENDLY 0.5A LI-ION CHARGER WITH POWER-PATH, 10.5V OVP 16-VQFN -5 TO 125
| Part | Mounting Type | Battery Chemistry | Current - Charging | Charge Current - Max [Max] | Package / Case | Operating Temperature [Min] | Operating Temperature [Max] | Voltage - Supply (Max) [Max] | Programmable Features | Fault Protection | Interface | Battery Pack Voltage | Supplier Device Package | Number of Cells | Function | Supplied Contents | Primary Attributes | Embedded | Utilized IC / Part | Type | Secondary Attributes |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Texas Instruments BQ24232HARGTR | Surface Mount | Lithium Ion | Constant - Programmable | 500 mA | 16-VFQFN Exposed Pad | -5 °C | 125 °C | 10.2 V | Current, Timer | Over Temperature, Over Voltage, Reverse Current, Short Circuit | USB | 4.31 V | 16-VQFN (3x3) | 1 | |||||||
Texas Instruments BQ24232RGTR | Surface Mount | Lithium Ion | Constant - Programmable | 500 mA | 16-VFQFN Exposed Pad | -40 °C | 125 ¯C | 10.2 V | Current, Timer | Over Temperature, Over Voltage, Reverse Current, Short Circuit | USB | 4.2 V | 16-VQFN (3x3) | 1 | |||||||
Texas Instruments BQ24232EVM | Battery Charger | Board(s) | Li-Ion / Li-Pol (1 Cell) | BQ24232 | Power Management | Charge Timer | |||||||||||||||
Texas Instruments BQ24232HARGTT | Surface Mount | Lithium Ion | Constant - Programmable | 500 mA | 16-VFQFN Exposed Pad | -5 °C | 125 °C | 10.2 V | Current, Timer | Over Temperature, Over Voltage, Reverse Current, Short Circuit | USB | 4.31 V | 16-VQFN (3x3) | 1 | |||||||
Texas Instruments BQ24232HRGTT | Surface Mount | Lithium Ion | Constant - Programmable | 500 mA | 16-VFQFN Exposed Pad | -40 °C | 125 ¯C | 10.2 V | Current, Timer | Over Temperature, Over Voltage, Reverse Current, Short Circuit | USB | 4.35 V | 16-VQFN (3x3) | 1 | |||||||
Texas Instruments BQ24232RGTT | Surface Mount | Lithium Ion | Constant - Programmable | 500 mA | 16-VFQFN Exposed Pad | -40 °C | 125 ¯C | 10.2 V | Current, Timer | Over Temperature, Over Voltage, Reverse Current, Short Circuit | USB | 4.2 V | 16-VQFN (3x3) | 1 | |||||||
Texas Instruments BQ24232HRGTR | Surface Mount | Lithium Ion | Constant - Programmable | 500 mA | 16-VFQFN Exposed Pad | -40 °C | 125 ¯C | 10.2 V | Current, Timer | Over Temperature, Over Voltage, Reverse Current, Short Circuit | USB | 4.35 V | 16-VQFN (3x3) | 1 | |||||||
Texas Instruments BQ24232HEVM-608 | Battery Charger | Board(s) | BQ24232H | Power Management | On-Board LEDs |
Description
General part information
BQ24232 Series
BQ24232 Battery Charger Power Management Evaluation Board
